Chapter 3 Preparation — Mounting accessories

Mounting accessories

You can mount and use equipment you have.

Accessory mounting holes

f The mounting screw size is M3.

f The mounting hole depth is 6 mm.

Do not over-tighten the screws when mounting accessories to the camera.
