1. Functions in each area
Y LAN connector [LAN] (RJ-45) (10BASE-T)
Z RS-422 interface connector [RS-422] (D-sub 9-pin, female, inch screw)
For details on connection, refer to “6. External interfaces”.
[ Tally output connector [TALLY] (D-sub 15-pin, male, inch screw)
For details on connection, refer to “6. External interfaces”.
\ GPI input connector [GPI] (3.5 mm diameter stereo mini jack)
For details on connection, refer to “6. External interfaces”.
] Ground connector
Connect to the system’s earth ground.
^ AC power input socket [ IN] (AC 220 V to 240 V)
Connect one end of the supplied power cable to this socket and the other end to the AC outlet.
The supplied power cable comes with a 3-pin power plug. Be absolutely sure to plug it into a 3-point power
outlet as the power source in order to earth the unit securely.
If a 3-point power outlet is not available for this connection, be absolutely sure to consult your dealer.
_ Power switch
This is used to turn the power on and off.
