4. Input/output signal settings
1 Press the [FUNC] button to light its indicator, and press the [IN/OUT] button to display the IN/OUT menu.
2
Turn [F1] to display the Multi1 sub menu.
<Menu display>
Multi1 Split Pos Signal
6/15 10Split 1 IN1
4Split
8Split
1-8 IN1-8
FMEM1
FMEM2
CBGD
Upper-L
Upper-R
PGM
PVW
AUX
KeyOut
3 Turn [F2] to select the display mode using the Split item.
4
Turn [F4] to select the position (1 to 8, Upper-L and Upper-R in the figures) using the Pos item, and turn
[F5] to set the name of the signal using the Signal item.
Different settings are stored for 10-division mode, 4-division mode and 8-division mode.
1 to 8:
This can be set to IN1 to IN8, FMEM1, FMEM2 or CBGD.
IN1 to IN8 is the default setting for Pos1 to Pos8 in any of the modes.
Upper-L, Upper-R:
These can be set to PGM, PVW, AUX or KeyOut.
They cannot be set when the 4-division mode (4Split) is selected.
The default settings are PGM for Upper-L and PVW for Upper-R.
The names of the signals selected as the AUX output signals are displayed in [ ] as with [CLN], [PVW]
and [PGM].
Some signal names are abbreviated as shown below, and displayed.
FMEM1  [FM1], FMEM
2  [FM2], CBGD  [CBG], CBAR  [BAR]
