3. Basic operations
3-2-5. Modifying wipe
Setting the lighting effect
Lighting effects can be added when the following wipe patterns have been selected:
3D page:
#1, #3, #7, #9
1
Press the [FUNC] button to light its indicator, and press the [WIPE] button to display the WIPE menu.
2
Turn [F1] to display the Modify sub menu.
<Menu display>
Modify Light-B Light-K Trim 4:3Auto
5/5 Off Off 16:9 Off
On
On 4:3
4:3Smth
Off
On
3 Turn [F2] to select whether the lighting effect at the time a background transition is executed is to be added
using the Light-B item.
On: The lighting eff
ect is added.
Off: The lighting eff
ect is not added.
4
Turn [F3] to select whether the lighting effect at the time a key transition is executed is to be added using the
Light-K item.
On: The lighting eff
ect is added.
Off: The lighting eff
ect is not added.
Setting the trimming
When SQ, SL or 3D has been selected as the wipe pattern, the trimming at the time a background transition is
executed can be set.
The “4:3” and “4:3Smth” settings for the Trim item take effect when the HD format has been selected as the
system format setting.
1
On the WIPE menu, turn [F1] to display the Modify sub menu.
2
Turn [F4] to set the trimming operation and transition operation using the Trim item.
16:9 (On):
For trimming the edges around the material.
This setting is used when a black border, for instance, can be seen around the material.
When HD has been selected as the system format setting, “16:9” is displayed on the menu, but
when SD has been selected as the system format setting, “On” is displayed on the menu.
4:3:
For trimming using the 4:3 aspect ratio and releasing the trimming when the transition is
completed.
4:3Smth:
For trimming using the 4:3 aspect ratio and executing the transition to 16:9 images smoothly.
Off:
No trimming
3
Turn [F5] to select the setting for automatic trimming (4:3 or 4:3Smth) in accordance with the material using
the 4:3Auto item.
Off:
All input materials are targeted for automatic trimming.
On:
Using the up-converter setting, the input materials for which EC (edge crop) is selected are targeted for
automatic trimming.
