5. System settings
5-6. Other settings
5-6-1. Setting the LCD backlight
The LCD backlight can be set to ON or OFF.
1
Press the [FUNC] button to light its indicator, and press the [SYSTEM] button to display the SYSTEM menu.
2
Turn [F1] to display the System sub menu.
3
Turn [F3], and select On or Off for the backlight using the LCD-BL item.
<Menu display>
System BusMode LCD-BL EditEN Protcol
2/16 PGM/PST On On GVG-A
A/B
Off Off GVG-B
P/TCont
P/TDirt
5-6-2. Setting editor enable
The user can set whether to enable control from an external device (editor) connected to the RS-422 connector.
On the System sub menu, turn [F4] to set On or Off for control from the external device (editor) connected to
the RS-4
22 connector using the EditEN item.
On: Control is enab
led.
Off: Control is disab
led.
EditEN item On and Off can be assigned to one of the user buttons. See
5-3-1.
5-6-3. Setting the protocol
Set the RS-422 protocol.
On the System sub menu, turn [F5] to set the protocol using the Protcol item.
GVG-A:
The GVG protocol is complied with.
The wipe pattern number starts from 0. See 6-1.
GVG-B:
The GVG protocol is complied with.
The wipe pattern number starts from 1. See 6-1.
P/TCont:
The controller for the camera or controller for the pan-tilt head is controlled.
This setting is selected when the unit is connected to a controller and a multiple number of
cameras or pan-tilt heads are to be controlled.
P/TDirt:
This setting is selected when the unit is connected directly to a pan-tilt head, and a camera or
pan-tilt head is to be controlled.
If “P/TCont” or “P/TDirt” is selected as the Protcol item setting, “—” is displayed for the EditEN item.
At this time, the user buttons will not work.
