Panasonic AV-HS400AE - 4-4-. Assigning the Output Signals

70
4. Input/output signal settings
4-4-2. Assigning the output signals
Assign the output signals to OUTPUT1 to 6.
1
Press the [FUNC] button to light its indicator, and press the [IN/OUT] button to display the IN/OUT menu.
2
Turn [F1] to display the Output sub menu.
3
Turn [F2] to select the signal name using the Signal item, and turn [F3] to set the type of output signal using
the Output item.
<Men
u display>
Output Signal Output Mode
2/15 OUT1 PGM

Normal
OUT1-6
PVW
AUX
Multi
KEYOut
DC
4 When the SDI output board (option) has been connected, turn [F4] to set the output mode using the Mode
item, and press the [F4] switch to enter the setting.
An aster
isk () appears on the left of the currently selected output mode.
Normal:
The same signals as the system format signals are output.
DC (down-converter):
When the system f
ormat is 1080/59.94i or 720/59.94p, the signals are output in the 480/59.94i format.
When the system format is 1080/50i or 720/50p, the signals are output in the 576/50i format.
When the system format is SD (480/59.94i or 576/50i), this setting cannot be selected.
