10
3. Specifications
Model
Indoor CS-Z25UB4EAW CS-Z35UB4EAW
Outdoor CU-Z25UBEA CU-Z35UBEA
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 2.50 3.20 0.85 3.50 4.00
BTU/h 2900 8530 10900 2900 11900 13600
Kcal/h 730 2150 2750 730 3010 3440
Running Current A – 2.50 – – 4.10 –
Input Power W 240 550 820 240 900 1.18k
Annual Consumption kWh – 275 – – 450 –
EER
W/W 3.54 4.55 3.90 3.54 3.89 3.39
BTU/hW 12.08 15.51 13.29 12.08 13.22 11.53
Kcal/hW 3.04 3.91 3.35 3.04 3.34 2.92
ErP
Pdesign kW 2.5 3.5
SEER (W/W) 6.3 6.5
Annual
Consumption
kWh 139 188
Class A++ A++
Power Factor % – 96 – – 95 –
Indoor Noise (H / L / QLo)
dB-A 34 / 25 / 22 34 / 26 / 23
Power Level dB 50 / – 50 / –
Outdoor Noise (H / L)
dB-A 46 / – 48 / –
Power Level dB 61 / – 63 / –
Heating
Capacity
kW 0.85 3.20 4.80 0.85 4.50 5.60
BTU/h 2900 10900 16400 2900 15300 19100
Kcal/h 730 2750 4130 730 3870 4820
Running Current A – 3.60 – – 6.00 –
Input Power W 230 790 1.32k 230 1.36k 1.75k
COP
W/W 3.70 4.05 3.64 3.70 3.31 3.20
BTU/hW 12.61 13.80 12.42 12.61 11.25 10.91
Kcal/hW 3.17 3.48 3.13 3.17 2.85 2.75
ErP
Pdesign kW 2.7 3.0
Tbivalent °C -10 -10
SCOP (W/W) 4.3 4.2
Annual
Consumption
kWh 879 1000
Class A+ A+
Power Factor % – 95 – – 99 –
Indoor Noise (H / L / QLo)
dB-A 35 / 28 / 25 35 / 28 / 25
Power Level dB 51 / – 51 / –
Outdoor Noise (H / L)
dB-A 47 / – 48 / –
Power Level dB 62 / – 63 / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 3.48 / 1.17k / 2.97 4.06 / 1.55k / 2.62
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 2.88 / 1.19k / 2.42 3.37 / 1.60k / 2.11
Max Current (A) / Max Input Power (W) 6.2 / 1.32k 8.0 / 1.75k
Starting Current (A) 3.60 6.00
