Model
Indoor CS-Z20VKEW / CS-XZ20VKEW CS-Z25VKEW / CS-XZ25VKEW
Outdoor CU-Z20VKE CU-Z25VKE
Compressor
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless Motor (6-poles) Brushless Motor (6-poles)
Output Power W 500 700
Indoor Fan
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type DC Motor (8-poles) DC Motor (8-poles)
Input Power W 47.3 47.3
Output Power W 40 40
Speed
QLo
Cool rpm 610 600
Heat rpm 610 620
Lo
Cool rpm 700 740
Heat rpm 780 860
Me
Cool rpm 880 960
Heat rpm 960 1080
Hi
Cool rpm 1060 1190
Heat rpm 1140 1300
SHi
Cool rpm 1090 1240
Heat rpm 1170 1350
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC Motor (8-poles) DC Motor (8-poles)
Input Power W – –
Output Power W 40 40
Speed Hi
Cool rpm 780 820
Heat rpm 700 780
Moisture Removal L/h (Pt/h) 1.3 (2.7) 1.5 (3.2)
Indoor
Airflow
QLo
Cool m
3
/min (ft
3
/min) 5.06 (179) 4.92 (174)
Heat m
3
/min (ft
3
/min) 5.06 (179) 5.10 (180)
Lo
Cool m
3
/min (ft
3
/min) 6.02 (213) 6.17 (218)
Heat m
3
/min (ft
3
/min) 6.87 (243) 7.24 (256)
Me
Cool m
3
/min (ft
3
/min) 7.93 (280) 8.13 (287)
Heat m
3
/min (ft
3
/min) 8.78 (310) 9.19 (325)
Hi
Cool m
3
/min (ft
3
/min) 9.90 (350) 10.20 (360)
Heat m
3
/min (ft
3
/min) 10.70 (380) 11.20 (395)
SHi
Cool m
3
/min (ft
3
/min) 10.17 (359) 10.62 (375)
Heat m
3
/min (ft
3
/min) 11.02 (389) 11.60 (410)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 26.9 (950) 28.7 (1015)
Heat m
3
/min (ft
3
/min) 24.1 (850) 27.2 (960)
Refrigeration
Cycle
Control Device Expansion valve Expansion valve
Refrigerant Oil cm
3
Ester oil VG 74 (260) FW50S (320)
Refrigerant Type g (oz) R32, 700 (24.7) R32, 850 (30.0)
F-Gas
GWP 675 675
CO2eq (ton)
(Precharged Amount /
Maximum Charged Amount)
0.473 / 0.523 0.574 / 0.624

Panasonic CS-Z25VKEW Specifications

General

AC input voltage	230 V
Design load (cooling)	2.5 kW
Annual energy consumption (cooling)	103 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	2.7 kW
Energy efficiency class (heating) (Colder heating season)	-
Energy efficiency class (heating) (Average heating season)	A+++
Annual energy consumption (heating) (Average heating season)	741 kWh
Type	Air conditioner indoor unit
Multi-split	No
Product color	White
Dehumidifying capacity	1.5 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3200 W
Cooling capacity in watts (min)	850 W
Heating capacity in watts (max)	5000 W
Heating capacity in watts (min)	800 W
Cooling capacity in watts (nominal)	2500 W
Cooling energy efficiency (EER, W/W)	4.81
Heating energy efficiency (COP, W/W)	4.79
Seasonal efficiency rating (cooling) (SEER)	8.5
Seasonal efficiency rating (heating) (SCOP)	5.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	3400 W
Indoor unit type	Wall-mountable
Indoor unit depth	194 mm
Indoor unit width	919 mm
Indoor unit height	295 mm
Indoor unit weight	10000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	612 m³/h
Heating airflow (indoor unit)	672 m³/h
Indoor unit sound power level	55 dB
Indoor unit noise level (low speed)	19 dB
Indoor unit noise level (high speed)	39 dB
Wi-Fi	Yes
Outdoor unit noise level	- dB
