11. Printed Circuit Board
11.1 Indoor Unit
11.1.1 Main Printed Circuit Board
AC303
CN-STM2
CN-STM1
CN-STM3
CN-RCV
CN-DATA1
CN-DISP
CN-RMT
CN-TH
JP1 (Random Auto Restart enable/disable)
CN-DATA3
CN-CNT
CN-DATA2
RY-PWR
CN-FM
