20.1.4 CS-Z42VKEW/CU-Z42VKE
Indoor (°C) Outdoor DB (°C)
DB WB
-10 -7
0 5 16 25 35
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19.0 4805 3187 892 4827 3207 887 4847 3160 892 4709 3179 1038 5301 3432 709 4942 3355 941 4200 3095 1240
22.0 5300 2564 902 5215 2562 981 5241 2556 954 5451 2621 827 5838 2787 679 5415 2634 929 4828 2469 1221
23
15.7 4292 3155 955 4324 3142 912 4281 3112 998 4307 3089 973 4776 3318 732 4430 3215 950 3918 3079 1216
18.4 4745 2543 892 4779 2539 863 4811 2555 892 4630 2511 1017 5076 2658 714 4832 2623 942 4344 2460 1217
20
13.3 3812 2951 1092 3777 2913 913 4077 3093 955 3956 2984 997 4493 3314 749 4080 3135 953 3640 2937 1213
15.8 4330 2510 953 4318 2504 904 4293 2473 1002 4210 2438 1047 4724 2643 731 4401 2542 948 3948 2390 1217
(Dry bulb value based on 46% humidity)
20.1.5 CS-Z50VKEW/CU-Z50VKE CS-XZ50VKEW/CU-Z50VKE
Indoor (°C) Outdoor DB (°C)
DB WB
-10 -7
0 5 16 25 35
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19.0 5646 4533 1038 5762 4538 934 5808 4589 950 5729 4577 924 5859 4603 872 5439 4388 1103 5000 4246 1410
22.0 6394 3701 914 6429 3695 854 6289 3664 982 6210 3582 974 6442 3669 833 5970 3467 1118 5501 3319 1428
23
15.7 5281 4531 940 5294 4546 867 5140 4450 975 5292 4556 898 5097 4370 900 4876 4204 1113 4542 4223 1410
18.4 5718 3681 887 5728 3676 924 5536 3581 1031 5739 3665 930 5600 3499 877 5328 3452 1133 4949 3307 1423
20
13.3 4097 3956 774 4056 3986 824 3860 3821 646 3489 3454 524 4966 4916 920 4491 4101 1117 4219 4028 1407
15.8 5140 3534 1017 4345 3115 807 4513 3156 777 4020 2976 553 5212 3478 897 4852 3346 1141 4498 3212 1423
(Dry bulb value based on 46% humidity)
20.1.6 CS-Z71VKEW/CU-Z71VKE
Indoor (°C) Outdoor DB (°C)
DB WB
-10 -7
0 5 16 25 35
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
27
19.0 8017 5673 1597 8181 5679 1438 8248 5742 1462 8135 5728 1422 8319 5761 1341 7724 5491 1697 7100 5313 2170
22.0 9079 4631 1407 9129 4624 1315 8931 4585 1512 8818 4483 1499 9147 4591 1282 8477 4339 1720 7811 4154 2197
23
15.7 7499 5671 1447 7518 5689 1334 7298 5568 1500 7515 5701 1382 7238 5468 1386 6923 5262 1713 6450 5285 2170
18.4 8119 4607 1365 8133 4601 1422 7860 4482 1587 8149 4586 1431 7953 4378 1349 7565 4321 1744 7027 4139 2191
20
13.3 5817 4950 1191 5760 4988 1268 5481 4964 995 4954 4470 806 7052 6981 1417 6377 5132 1719 5992 5041 2165
15.8 7299 4423 1566 6170 3898 1241 6408 3949 1195 5709 3725 851 7402 4353 1381 6889 4187 1755 6387 4020 2190
(Dry bulb value based on 46% humidity)
TC - Total Cooling Capacity (W)
SHC - Sensible Heat Capacity (W)
IP - Input Power (W)

Panasonic CS-Z25VKEW Specifications

General

AC input voltage	230 V
Design load (cooling)	2.5 kW
Annual energy consumption (cooling)	103 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	2.7 kW
Energy efficiency class (heating) (Colder heating season)	-
Energy efficiency class (heating) (Average heating season)	A+++
Annual energy consumption (heating) (Average heating season)	741 kWh
Type	Air conditioner indoor unit
Multi-split	No
Product color	White
Dehumidifying capacity	1.5 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3200 W
Cooling capacity in watts (min)	850 W
Heating capacity in watts (max)	5000 W
Heating capacity in watts (min)	800 W
Cooling capacity in watts (nominal)	2500 W
Cooling energy efficiency (EER, W/W)	4.81
Heating energy efficiency (COP, W/W)	4.79
Seasonal efficiency rating (cooling) (SEER)	8.5
Seasonal efficiency rating (heating) (SCOP)	5.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	3400 W
Indoor unit type	Wall-mountable
Indoor unit depth	194 mm
Indoor unit width	919 mm
Indoor unit height	295 mm
Indoor unit weight	10000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	612 m³/h
Heating airflow (indoor unit)	672 m³/h
Indoor unit sound power level	55 dB
Indoor unit noise level (low speed)	19 dB
Indoor unit noise level (high speed)	39 dB
Wi-Fi	Yes
Outdoor unit noise level	- dB
