Panasonic CS-Z25VKEW Installation Instruction

24
 Multi Split Combination Possibility:
o A single outdoor unit enables air conditioning of up to four separate rooms for CU-4E23PBE, CU-4E27PBE.
o A single outdoor unit enables air conditioning of up to five separate rooms for CU-5E34PBE.
CONNECTABLE INDOOR UNIT
OUTDOOR UNIT
CU-4E23PBE* CU-4E27PBE* CU-5E34PBE*
ROOM
TYPE
A B C D A B C D A B C D E
Wall
1.6kW
CS-MZ16VKE
CS-MRZ16VKE
● ● ● ● ● ● ● ● ● ● ● ● ●
2.0kW
CS-Z20VKEW
CS-XZ20VKEW
CS-RZ20VKEW
● ● ● ● ● ● ● ● ● ● ● ● ●
2.5kW
CS-Z25VKEW
CS-XZ25VKEW
CS-RZ25VKEW
● ● ● ● ● ● ● ● ● ● ● ● ●
3.2kW
CS-Z35VKEW
CS-XZ35VKEW
CS-RZ35VKEW
● ● ● – ● ● ● ● ● ● ● ● ●
4.0kW
CS-Z42VKEW
CS-RZ42VKEW
● ● – – ● ● ● – ● ● ● ● –
5.0kW
CS-Z50VKEW
CS-XZ50VKEW
CS-RZ50VKEW
● ● – – ● ● – – ● ● ● – –
6.0kW CS-RZ60VKEW ● – – – ● ● – – ● ● – – –
7.1kW
CS-Z71VKEW
CS-RZ71VKEW
● – – – ● – – – ● ● – – –
Capacity range of
connectable units
From 4.5kW to 11.0kW From 4.5kW to 13.6kW From 4.5kW to 17.5kW
Pipe length
1 room maximum pipe length (m) 25 25 25
Allowable elevation (m) 15 15 15
Total allowable pipe length (m) 60 70 80
Total pipe length for maximum
chargeless length (m)
30 45 45
Additional gas amount over
chargeless length (g/m)
20 20 20
Note: “●” : Available
Remarks for CU-4E23PBE / CU-4E27PBE / CU-5E34PBE
1. At least two indoor units must be connected.
2. The total nominal cooling capacity of indoor unit that will be connected to outdoor unit must be within connectable capacity range of
indoor unit. (as shown in the table above)
Example: The indoor units’ combination below is possible to connect to CU-4E27PBE. (Total nominal capacity of indoor units is between
4.5kW to 13.6kW)
1) Two CS-XZ25VKEW only. (Total nominal cooling capacity is 5.0kW)
Note*: Above outdoor unit is contains and operates with refrigerant R410A gas.

Panasonic CS-Z25VKEW Specifications

General

AC input voltage	230 V
Design load (cooling)	2.5 kW
Annual energy consumption (cooling)	103 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	2.7 kW
Energy efficiency class (heating) (Colder heating season)	-
Energy efficiency class (heating) (Average heating season)	A+++
Annual energy consumption (heating) (Average heating season)	741 kWh
Type	Air conditioner indoor unit
Multi-split	No
Product color	White
Dehumidifying capacity	1.5 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3200 W
Cooling capacity in watts (min)	850 W
Heating capacity in watts (max)	5000 W
Heating capacity in watts (min)	800 W
Cooling capacity in watts (nominal)	2500 W
Cooling energy efficiency (EER, W/W)	4.81
Heating energy efficiency (COP, W/W)	4.79
Seasonal efficiency rating (cooling) (SEER)	8.5
Seasonal efficiency rating (heating) (SCOP)	5.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	3400 W
Indoor unit type	Wall-mountable
Indoor unit depth	194 mm
Indoor unit width	919 mm
Indoor unit height	295 mm
Indoor unit weight	10000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	612 m³/h
Heating airflow (indoor unit)	672 m³/h
Indoor unit sound power level	55 dB
Indoor unit noise level (low speed)	19 dB
Indoor unit noise level (high speed)	39 dB
Wi-Fi	Yes
Outdoor unit noise level	- dB
