14.14.3 Application Installation
For Android user (Android 4.4 and above)
 Open
GET IT ON
Google Play
.
 Search for Panasonic Comfort Cloud app.
 Download and install.
For iOS user (iOS 9 and above)
 Open
Download on the
App Store
.
 Search for Panasonic Comfort Cloud app.
 Download and install.
Note
 The app user interface image may change for version upgrade without notification.
 There is no charge for using this application. However, other charges may be incurred for connection and
operation.
14.14.4 To Disconnect Wireless LAN (Off Wireless LAN LED)
 Press and release one time at the Remote Control Wireless LAN button and the LED will turn off. (LED ON ->
LED OFF).
14.14.5 To Delete Wireless LAN Information
 If Wireless LAN is off (LED is Off), turn on Wireless LAN first by press and release one time the Wireless LAN
button. (LED OFF -> LED ON).
 Push Wireless LAN button for 5 seconds.
 In the Remote Control Operation select “5” and push for 3 seconds.
 Initilization is finish and Wireless LAN LED will off automatically.
14.14.6 To Check Wireless LAN Signal Strength
 Confirm the air conditioner operation is stopped and press the Wireless LAN button for 5 seconds.
 Select “4” in the remocon then press set button and operation stops.
 After 5 seconds, the signal strength is shown on the indoor unit Wireless LAN LED.
Strong Signal: Blink 3 times with an interval.
Moderate Signal: Blink 2 times with an interval.
Weak Signal: Blink once with an interval.
No Signal: OFF.
 It will stop automatically after 10 minutes. To stop immediately, press Wireless LAN button.
14.14.7 Wireless LAN Failure Diagnosis
14.14.7.1 Between ID Micon and Wireless LAN Module Failure Detect Condition
 When module and ID micon (CN-LAN) communication is following below condition.
o No response against sending data.
o Reply error against sending data.
o Regularly sending from AC unit (Every 1 minutes).
 Either one from above condition occur, detection will start.
 If for certain time there is no communication and retry is implemented 3 times continuously confirm the error by
following below table.
 When failure diagnosis H85 occur.
Wireless LAN LED Timer LED
When error condition check Light up No light
When retry Light up No light
After confirm failure No light Blinking

Panasonic CS-Z25VKEW Specifications

General

AC input voltage	230 V
Design load (cooling)	2.5 kW
Annual energy consumption (cooling)	103 kWh
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	2.7 kW
Energy efficiency class (heating) (Colder heating season)	-
Energy efficiency class (heating) (Average heating season)	A+++
Annual energy consumption (heating) (Average heating season)	741 kWh
Type	Air conditioner indoor unit
Multi-split	No
Product color	White
Dehumidifying capacity	1.5 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3200 W
Cooling capacity in watts (min)	850 W
Heating capacity in watts (max)	5000 W
Heating capacity in watts (min)	800 W
Cooling capacity in watts (nominal)	2500 W
Cooling energy efficiency (EER, W/W)	4.81
Heating energy efficiency (COP, W/W)	4.79
Seasonal efficiency rating (cooling) (SEER)	8.5
Seasonal efficiency rating (heating) (SCOP)	5.1
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	3400 W
Indoor unit type	Wall-mountable
Indoor unit depth	194 mm
Indoor unit width	919 mm
Indoor unit height	295 mm
Indoor unit weight	10000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	612 m³/h
Heating airflow (indoor unit)	672 m³/h
Indoor unit sound power level	55 dB
Indoor unit noise level (low speed)	19 dB
Indoor unit noise level (high speed)	39 dB
Wi-Fi	Yes
Outdoor unit noise level	- dB
