201
KX-FP365CX / KX-FM388CX
20.2. Replacement Parts List
Notes:
1. The “RTL” marking indicates that its Retention Time is
Limited.
When production is discontinued, this item will continue to
be available only for a specific period of time. This period
of time depends on the type of item, and the local laws
governing parts and product retention.
At the end of this period, the item will no longer be avail-
able.
2. Important safety notice
Components identified by mark have special charac-
teristics important for safety. When replacing any of these
components, use only manufacture's specified parts.
3. The S mark means the part is one of some identical parts.
For that reason, it may be different from the installed part.
4. RESISTORS & CAPACITORS
Unless otherwise specified;
All resistors are in ohms (Ω) K=1000Ω, M=1000kΩ
All capacitors are in MICRO FARADS (µF) P=µµF
*Type & Wattage of Resistor
20.2.1. Cabinet and Electrical Parts
20.2.1.1. Operation Cover Section
20.2.1.2. Back Cover Section
20.2.1.3. Upper Cabinet Section
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
1 PFGV1022Y TRANSPARENT PLATE PC
2 PNGD1012Z CARD, TEL
3 PNGP1056Z PANEL, LCD (for KX-FP365) PC
3 PNGP1057Z PANEL, LCD (for KX-FM388) PC
4 PFHX2102Z PLASTIC PARTS, RING STOP PC
5 PFHX2104Z PLASTIC PARTS, RING START PC
6 PFHX2103Z PLASTIC PARTS, RING COPY PC
7 PFGG1315D1 GRILLE, OPERATION PANEL
(for KX-FP365)
PS-HB
7 PFGG1315B1 GRILLE, OPERATION PANEL
(for KX-FM388)
PS-HB
8 PFDR1105Z ROLLER, DOCUMENT EXIT
9 PFDG1148Z GEAR, DOCUMENT EXIT ROLLER POM-HB
10 PFHG1283Z RUBBER SPACER, PAD
11 PFHR1719Z COVER, SEPARATION HOLDER ABS
12 PFHR1720Z SPACER, DOCUMENT FEED SUP-
PORT
POM-HB
13 PFUS1836Z SPRING
14 PFUS1837Z SPRING, DOCUMENT FEED
15 PFUV1112Z COVER, OPERATION PANEL PS-HB
16 PFJS08M93Z CONNECTOR, 8 PIN
17 PFBX1290Y1 PUSH BUTTON, 11 KEY ABS
18 PFBX1289Y3 PUSH BUTTON, 3 KEY ABS
19 PFBX1291Z1 PUSH BUTTON, 16 KEY ABS
20 PFBC1203Z3 PUSH BUTTON, NAVIGATOR ABS
21 PNHX1164Z TAPE
22 PNJS021027Z CONNECTOR
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
32 PFDE1189X2 LEVER, CASSETTE S
PS-HB
33 PFKV1071X2 COVER, U TURN S
PS-HB
34 PFQT2999Z INDICATION LABEL, PAPER
SET
35 PNGT1909Y-M NAME PLATE (for KX-FP365)
35 PNGT1923Y-M NAME PLATE (for KX-FM388)
36 PFQT2980Z INDICATION LABEL, OPEN
37 PFKS1039Z TRAY, CASSETTE PLATE PS-HB
38 PFUS1414Z SPRING, PICK UP
39 PFHG1088Z RUBBER PARTS, PAPER
SEPARATION
40 PFUS1409Z SPRING, EARTH
41 PFDR1040Z ROLLER, SUPPORT POM-HB
42 PFUS1407Y SPRING, EXIT SUB ROLLER
43 PFUV1055Y COVER, GUIDE PS-HB
44 PFHR1221Y GUIDE, CORNER (RIGHT) POM-HB
45 PFHR1220X GUIDE, CORNER (LEFT) POM-HB
46 PFDN1062Z ROLLER, PICK UP POM-N
47 PFDE1188Z SPACER, PICK UP DELAY POM-HB
48 PFDG1290Z GEAR, PICK UP ROLLER POM-HB
49 PFDG1293Z GEAR, DOCUMENT POM-HB
50 PFUS1034Z SPRING, GUIDE DOCUMENT
51 PFHX1605Z SPACER, SLIDER GEAR SHEET PET
52 PFKR1028Y1 GUIDE, DOCUMENT (RIGHT) ABS-HB
53 PFKR1027X1 GUIDE, DOCUMENT (LEFT) ABS-HB
54 PFDN1043Z ROLLER, PLATEN
55 PFHR1717Z SPACER, PLATEN ROLLER
(LEFT)
POM-HB
56 PFHR1718Z SPACER, PLATEN ROLLER
(RIGHT)
POM-HB
57 PFDG1165Y GEAR, PLATEN ROLLER POM-HB
58 PFDE1192Y1 LEVER, LOCK ABS-HB
59 PFUS1404Z SPRING, EARTH LEVER
60 PFUS1258Z SPRING, LOCK LEVER
61 PFHX1596Z SPACER, LOCK LEVER SHEET PET
62 PFUS1232Z SPRING, BACK TENSION
63 PFDG1160Z GEAR BACK TENSION POM-HB
64 PFHS1029Z COVER, BACK TENSION GS
65 PFDG1291Z GEAR, PICK UP IDLER POM-HB
66 PFDG1292Z GEAR, PICK UP IDLER POM-HB
67 PFUA1042X CHASSIS, U TURN PS-HB
68 PFDN1061Z ROLLER, EXIT (RIGHT) POM-N
69 PFDN1060Z ROLLER, EXIT (LEFT) POM-N
70 PFUG1015Y GUIDE, BASE PS-HB
71 PFDG1289Z GEAR, EXIT IDLER POM-HB
72 PFDG1288Z GEAR, EXIT ROLLER POM-HB
73 PFUS1237Z SPRING, PAPER TOP
74 PFDE1128Y LEVER, PAPER TOP SENSOR POM-HB
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
91 PFKM1231Z1 CABINET BODY, MAIN
(for KX-FP365)
PBT+AB
S-V1
Safe
ty
Ref.
No.
Part No. Part Name & Description Remark
s
