Panasonic KX-TG4732B

23
KX-TG4732B/KX-TG4733B/KX-TG4734B/KX-TGA470B
RF part signal route
SIGNAL ROUTE
IN 㸢㩷 ROUTE 㸢㩷 OUT
HANDSET RF
[ TX_ROUTE ]
HANDSET RF
[ RX_ROUTE ]
BASE UNIT RF
[ TX_ROUTE ]
BASE UNIT RF
[ RX_ROUTE ]
IC1(44/45) - L809 - C812 - DA801 - C803 - C801 - ANT
ANT - C801 - C803 - DA801 - C826 - IC1(46/47)
IC501(44/45) - C812 - L809 - DA801 - C895 - DA802 - C894/C893 - ANT1/ANT2
ANT1/ANT2 - C894/C893 - DA802 - C895 - DA801 - C826 - IC501(46/47)
Note:
: inside of Handset
