12.4. Adjustment Standard (Charger Unit)
When connecting the simulator equipment for checking, please refer to below.
12.4.1. Bottom View
D1
R1
F1
R2
A
PNLB2081Z -IG
PbF
Charge-
Charge+
12 /2 W
Digital
Volt Meter
DC POWER
DC 5.5 V
(GND)
