Panasonic KX-TG4732B

92
KX-TG4732B/KX-TG4733B/KX-TG4734B/KX-TGA470B
16.5. Replacement Parts List
1. RTL (Retention Time Limited)
Note:
The “RTL” marking indicates that its Retention Time is
Limited.
When production is discontinued, this item will
continue to be available only for a specific period of
time.
This period of time depends on the type of item, and
the local laws governing parts and product retention.
At the end of this period, the item will no longer be
available.
2. Important safety notice
Components identified by the mark indicates special
characteristics important for safety. When replacing any
of these components, only use specified manufacture's
parts.
3. The S mark means the part is one of some identical parts.
For that reason, it may be different from the installed part.
4. ISO code (Example: ABS-94HB) of the remarks column
shows quality of the material and a flame resisting grade
about plastics.
5. RESISTORS & CAPACITORS
Unless otherwise specified;
All resistors are in ohms (Ω) k=1000Ω, M=1000kΩ
All capacitors are in MICRO FARADS (µF) p=µµF
*Type & Wattage of Resistor
16.5.1. Base Unit
16.5.1.1. Cabinet and Electrical Parts
16.5.1.2. Main P.C. Board Parts
Note:
(*1) When replacing IC611 or X501, make the adjustment
using PNZZTG4741M. Refer to How to download the data
(P.58) of Things to Do after Replacing IC or X'tal.
(*2) When replacing the base unit LCD, See How to
Replace the Base Unit LCD (P.48).
Safety Ref.
No.
Part No. Part Name & Description Remarks
1 PNGP1225Z1 PANEL, UPPER PC-HB
2 PNKM1256Z1 CABINET BODY PS-HB
3 L0AA02A00087 SPEAKER
4 PQHG10729Z RUBBER PARTS, SPEAKER
5 PQHR11313Z GUIDE, SPEAKER POM-HB
6 PNKE1130Z1 CASE, CHARGE TERMINAL PS-HB
7 PNJT1107Z CHARGE TERMINAL
8 PNBC1404Y3 BUTTON, NAVIGATOR KEY ABS-HB
9 PNHR1585Z GUIDE, BUTTON PS-HB
10 PNBC1345Z1 BUTTON, MESSAGE PMMA-HB
11 PNJK1146Y KEYBOARD SWITCH, TAM
12 PNLA1047Z ANTENNA, SUB
13 PNHR1584Z GUIDE, JACK PS-HB
Type
ERC:Solid
ERDS:Carbon
ERJ:Chip
ERX:Metal Film
ERG:Metal Oxide
ER0:Metal Film
PQ4R: Chip
ERS:Fusible Resistor
ERF:Cement Resistor
Type
ECFD:Semi-Conductor
ECQS:Styrol
ECUV,PQCUV, ECUE:Chip
ECQMS:Mica
ECCD,ECKD,ECBT,F1K,ECUV:Ceramic
ECQE,ECQV,ECQG:Polyester
ECEA,ECST,EEE:Electlytic
ECQP:Polypropylene
Wattage
*Type & Voltage Of Capacitor
10,16:1/8W 14,25:1/4W 12:1/2W 1:1W 2:2W 3:3W
Voltage
ECQ Type ECQG
ECQV Type
05:50V
1:100V
2:200V
ECSZ Type
0J :6.3V
1A :10V
1C :16V
1E,25:25V
1V :35V
50,1H:50V
1J :16V
2A :100V
0F:3.15V
1A:10V
1V:35V
0J:6.3V
Others
1H:50V
2A:100V
2E:250V
2H:500V
14 PQJJ1T039L JACK, MODULAR
15 K2ECYZ000001 JACK, DC
16 PNKF1228Z1 CABINET COVER PS-HB
17 PNHA1013Z RUBBER PARTS, FOOT
CUSHION
18 PNGT6443Z NAME PLATE
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB1 PNWP1TG4731H MAIN P.C.BOARD ASS'Y
(RTL)
(ICs)
I C 3 0 2 C 0 D B E Y Y 0 0 1 0 2 I C
IC501 C2HBCY000080 IC(BBIC)
IC601 PNWI2TG4731H IC(FLASH)
IC611 PNWI1TG4731H IC(EEPROM)(*1)
(TRANSISTORS)
Q111 2SC6054JSL TRANSISTOR(SI) S
Q141 B1ACGP000008 TRANSISTOR(SI)
Q142 B1ABDM000001 TRANSISTOR(SI)
Q161 DSC7003S0L TRANSISTOR(SI)
Q171 2SC6054JSL TRANSISTOR(SI) S
Q651 PSVTUMG11NTR TRANSISTOR(SI) S
Q653 2SC6054JSL TRANSISTOR(SI) S
(DIODES)
D101 PQVDMD5S DIODE(SI)
D113 DA2J10100L DIODE(SI)
D133 DA2J10100L DIODE(SI)
D142 PQVDPTZT2530 DIODE(SI) S
D362 B0ECKM000008 DIODE(SI)
DA801 B0DDCD000001 DIODE(SI)
DA802 B0DDCD000001 DIODE(SI)
(COILS)
L 5 0 1 G 1 C R 1 0 J 0 0 0 1 0 C O I L
L 8 0 9 G 1 C 7 N 5 J A 0 0 4 4 C O I L
(RESISTOR ARRAYS)
RA151 D1H410220001 RESISTOR ARRAY
RA501 EXB28V330 RESISTOR ARRAY
RA502 EXB28V103 RESISTOR ARRAY
RA504 D1H468020001 RESISTOR ARRAY
RA651 EXB28V101JX RESISTOR ARRAY
RA652 EXB28V101JX RESISTOR ARRAY
(VARISTOR)
SA101 PQVDDSS301L VARISTOR (SURGE
ABSORBER)
S
(RESISTORS)
R 1 1 1 P Q 4 R 1 0 X J 1 0 4 1 0 0 k S
R 1 1 2 P Q 4 R 1 0 X J 1 0 4 1 0 0 k S
R 1 1 3 D 0 G B 1 0 3 J A 0 5 7 1 0 k
R 1 1 4 D 0 G B 4 7 3 J A 0 5 7 4 7 k
R 1 2 1 E R J 3 G E Y J 3 9 4 3 9 0 k S
R 1 2 2 E R J 3 G E Y J 3 9 4 3 9 0 k S
R 1 3 1 P Q 4 R 1 8 X J 1 0 6 1 0 M S
R 1 3 3 E R J 3 G E Y J 3 3 4 3 3 0 k S
R 1 3 6 D 0 G A 1 0 4 J A 0 2 1 1 0 0 k
R 1 4 1 D 0 G B 1 0 4 J A 0 5 7 1 0 0 k
R 1 4 2 P Q 4 R 1 8 X J 2 7 2 2 . 7 k S
R 1 4 5 D 0 G A 2 2 2 J A 0 2 1 2 . 2 k
R 1 5 1 D 0 G A 1 0 4 J A 0 2 1 1 0 0 k
R 1 5 2 E R J 2 G E J 4 7 4 X 4 7 0 k S
R160 ERJ3GEYJ911 910
R 1 6 1 D 0 G B 1 0 4 J A 0 5 7 1 0 0 k
R 1 6 2 D 0 G B 4 7 3 J A 0 5 7 4 7 k
R163 ERJ14YJ120U 12
Safety Ref.
No.
Part No. Part Name & Description Remarks
