47
KX-TG4732B/KX-TG4733B/KX-TG4734B/KX-TGA470B
11.1.3. Charger Unit
Ԙ
Remove the screw to remove
the cabinet cover.
ԙ
Remove the solders to remove
the 2 charge terminals.
Ԙ
Screw
ԙ
Solders
Main P.C. board
2 charge terminals
