KX-TG4732B/KX-TG4733B/KX-TG4734B/KX-TGA470B
4.4.4.1. Charge Circuit
The voltage from the AC adaptor is supplied to the charge circuits.
D362
R372 R371
D361
CHARGE+
F301
DCP
+
CHARGE-
( )
C306
+5.5V
DCM
