KX-TG4732B/KX-TG4733B/KX-TG4734B/KX-TGA470B
11 Disassembly and Assembly Instructions
11.1. Disassembly Instructions
11.1.1. Base Unit
Ԙ
Remove the 4 screws to remove
the cabinet cover.
ԙ
Remove the solders.
Ԛ
Remove the screw and pararell wire
to remove the main P.C. board.
Solders
ԙ
Cabinet cover
Ԙ
4 screws
Main P.C. board
Pararell wire
Ԛ
