16.5.1.3. Operational P.C. Board Parts
R164 D0GB272JA057 2.7k
R165 ERJ3GEYJ273 27k S
R167 D0GG270JA007 27
R171 D0GA220JA021 22
R172 D0GA104JA021 100k
R175 D0GA561JA021 560
R176 D0GA101JA021 100
R177 D0GA102JA021 1k
R178 D0GA102JA021 1k
R321 ERJ2RKF1400 140
R322 ERJ2RKF1000 100
R331 ERJ3EKF6802 68k
R332 ERJ3EKF3302 33k
R371 ERJ14YJ1R0U 1
R372 ERJ14YJ1R0U 1
R501 D0GB100JA057 10
R502 D0GA330JA015 33
R505 D0GA222JA021 2.2k
R510 D0GA102JA021 1k
R605 D0GA332JA015 3.3k
R606 D0GA332JA015 3.3k
R612 D0GA103JA021 10k
R651 D0GA681JA021 680
R652 D0GA681JA021 680
R654 D0GA222JA021 2.2k
R806 ERJ2GEJ471 470 S
R807 ERJ2GEJ471 470 S
R891 ERJ2GEJ471 470 S
R892 ERJ2GEJ471 470 S
(CAPACITORS)
C101 F1K2H681A008 680p
C102 F1K2H681A008 680p
C111 F1J2A473A024 0.047
C112 F1J2A473A024 0.047
C113 PQCUV1A684KB 0.68
C120 ECUE1H102KBQ 0.001 S
C121 F1K2H681A008 680p
C122 F1K2H681A008 680p
C123 ECUE1H100DCQ 10p S
C124 ECUE1H100DCQ 10p S
C132 ECUV1H103KBV 0.01
C142 ECUV1H103KBV 0.01
C151 ECUE1H100DCQ 10p S
C152 ECUE1C103KBQ 0.01 S
C161 F1K1E1060001 10
C168 ECUV1A225KBV 2.2 S
C171 ECUV1H472KBV 0.0047
C173 ECUV1A224KBV 0.22
C175 ECUE1H102KBQ 0.001 S
C176 PQCUV0J106KB 10 S
C178 ECUV1C223KBV 0.022
C184 ECUV1A105KBV 1
C186 ECUE1H100DCQ 10p S
C321 ECUV1A105KBV 1
C341 F2G0J3310025 330
C342 ECUV1C104KBV 0.1
C343 ECUE1H100DCQ 10p S
C351 ECUV1C105KBV 1
C476 ECUE1H100DCQ 10p S
C477 ECUE1H100DCQ 10p S
C478 ECUE1H100DCQ 10p S
C479 ECUE1H100DCQ 10p S
C501 ECUE1A104KBQ 0.1
C502 ECJ1VB0G106M 10 S
C503 ECJ1VB0G106M 10 S
C504 ECUE0J105KBQ 1
C505 ECJ1VB0G106M 10 S
C506 ECUV1A105KBV 1
C507 ECUV1A225KBV 2.2 S
C508 ECUE1H100DCQ 10p S
C509 ECUE1H120JCQ 12p S
C510 ECUV1A105KBV 1
C511 ECJ1VB0G106M 10 S
Safety Ref.
No.
Part No. Part Name & Description Remarks
C512 ECUE1A104KBQ 0.1
C513 ECUV1A225KBV 2.2 S
C514 ECUE1A104KBQ 0.1
C515 ECUV1A105KBV 1
C516 ECUE1A104KBQ 0.1
C517 ECUE1A104KBQ 0.1
C518 ECUE1A104KBQ 0.1
C519 ECUE1A104KBQ 0.1
C520 ECUE1A104KBQ 0.1
C521 ECUE0J105KBQ 1
C522 ECUE1H100DCQ 10p S
C530 ECUE1H100DCQ 10p S
C601 ECUE1A104KBQ 0.1
C611 ECUE1A104KBQ 0.1
C661 ECUE1A104KBQ 0.1
C805 F1G1H2R7A480 2.7p
C806 F1G1H2R7A480 2.7p
C810 F1G1H2R4A480 2.4p
C811 ECUE1H100DCQ 10p S
C812 F1G1HR90A480 0.9p
C813 F1G1H2R0A480 2p
C820 F1G1H1R5A480 1.5p
C822 ECUE1H100DCQ 10p S
C825 ECUE1H100DCQ 10p S
C826 ECUE1H100DCQ 10p S
C827 ECUE1H100DCQ 10p S
C859 F1G1H2R2A480 2.2p
C863 F1G1H1R5A480 1.5p
C891 F1G1H5R0A480 5p
C892 F1G1H5R0A480 5p
C893 ECUE1H100DCQ 10p S
C894 ECUE1H100DCQ 10p S
C895 F1G1H1R2A480 1.2p
C896 F1G1H2R2A480 2.2p
(OTHERS)
E1 L5DYBYY00021 LIQUID CRYSTAL DISPLAY
(*2)
E2 PNHX1406Z COVER, LCD SHEET
E3 PNHR1386Z GUIDE, LCD ABS-HB
P101 D4DAY220A022 THERMISTOR (POSISTOR)
F301 K5H302Y00003 FUSE
X501 H0J138500011 CRYSTAL OSCILLATOR (*1)
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB2 PNWP2TG4731H OPERATIONAL P.C.BOARD
ASS'Y (RTL)
(LEDS)
LED901 B3AAB0000347 LED
LED902 B3AAB0000347 LED
LED905 LNJ237W82RA LED
LED906 LNJ237W82RA LED
LED907 LNJ237W82RA LED
LED908 LNJ237W82RA LED
(RESISTORS)
R901 D0GA271JA015 270
R902 D0GA271JA015 270
R903 D0GA271JA015 270
R904 D0GA271JA015 270
(CAPACITORS)
C901 ECUV1C105KBV 1
C902 F1H1E1050001 1
C903 ECUE0J105KBQ 1
Safety Ref.
No.
Part No. Part Name & Description Remarks
