Panasonic KX-TG4732B

94
KX-TG4732B/KX-TG4733B/KX-TG4734B/KX-TGA470B
16.5.2. Handset
16.5.2.1. Cabinet and Electrical Parts
16.5.2.2. Main P.C. Board Parts
Note:
(*1) Reconfirm the model No. written on the handset's name
plate when replacing PCB100. Because the model No. of
the optional handset may differ from the included handset.
(*2) When replacing IC3 or X1, make the adjustment
using PNZZTG4741M. Refer to Handset (P.59) of Things
to Do after Replacing IC or X'tal.
(*3) When replacing the handset LCD, See How to
Replace the Handset LCD (P.50).
Safety Ref.
No.
Part No. Part Name & Description Remarks
101 PNGP1228Z1 PANEL, LCD PMMA-HB
102 PNYE1066Z TAPE, DOUBLE SIDED
103 PNKM1257Z1 CABINET BODY ABS-HB
104 PNGT6432Z NAME PLATE
105 L0AD01A00026 RECEIVER
106 PNYE1065Y SPACER, CUSHION LCD
107 PNBC1354Z1 BUTTON, NAVIGATOR KEY ABS-HB
108 PNJK1149Z KEYBOARD SWITCH
109 PNJT1027Y CHARGE TERMINAL (L)
110 PNJT1026Y CHARGE TERMINAL (R)
111 PNJK1150Z RUBBER PARTS, SIDE
SWITCH
112 PQHR11315Z GUIDE, SPEAKER ABS-HB
113 L0AA02A00096 SPEAKER
114 PQHS10784Y SPACER, SPEAKER NET
115 PQJC10056W BATTERY TERMINAL
116 PNKE1131Z1 COVER, EP CAP
117 PNKF1229Z1 CABINET COVER ABS-HB
118 PNHR1588Z OPTIC CONDUCTIVE PARTS,
LED LENS
PS-HB
119 PNQT2006Z LABEL, ATTENTION
120 PNQT2335Z LABEL, BATTERY
121 PNHS1079Z SPACER, BATTERY
122 PNKK1066Z1 LID, BATTERY ABS-HB
123 PNYNTGA470BR LID, BATTERY ASS'Y ABS-HB
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB100 PNWP1TGA470R MAIN P.C.BOARD ASS'Y
(RTL) (*1)
(ICs)
IC1 C2HBCY000081 IC
IC3 PNWITGA470BR IC(EEPROM)(*2)
IC4 C0DBZYY00357 IC
(TRANSISTORS)
Q2 B1ADCF000040 TRANSISTOR(SI)
Q3 B1ABGE000011 TRANSISTOR(SI)
Q4 B1ADCF000040 TRANSISTOR(SI)
Q5 DRC9113Z0L TRANSISTOR(SI)
Q6 DRC9113Z0L TRANSISTOR(SI)
Q9 2SC6054JSL TRANSISTOR(SI) S
(DIODES)
D13 B0BC4R3A0006 DIODE(SI)
D14 B0BC4R3A0006 DIODE(SI)
D21 B0BC4R3A0006 DIODE(SI)
D22 B0BC4R3A0006 DIODE(SI)
DA801 B0DDCD000001 DIODE(SI)
(LEDS)
LED1 B3ACB0000190 LED
LED2 B3ACB0000190 LED
LED3 B3ACB0000190 LED
LED4 B3ACB0000190 LED
LED5 B3ACB0000190 LED
LED6 B3ACB0000190 LED
LED11 B3ACB0000190 LED
LED12 B3ACB0000190 LED
(COILS)
C 8 1 2 P Q L Q R 4 C 8 N 2 J C O I L S
L 4 G 1 C R 1 8 J 0 0 0 0 4 C O I L
(RESISTOR ARRAYS)
RA2 D1H83314A013 RESISTOR ARRAY S
RA3 D1H83314A013 RESISTOR ARRAY S
RA4 D1H433220001 RESISTOR ARRAY
RA5 EXB28V332JX RESISTOR ARRAY
(IC FILTERS)
L 1 J 0 J C C 0 0 0 0 2 8 6 I C F I L T E R
L 3 J 0 J D C 0 0 0 0 0 4 5 I C F I L T E R
L 7 J 0 J C C 0 0 0 0 2 7 6 I C F I L T E R
L 1 0 J 0 J C C 0 0 0 0 2 8 6 I C F I L T E R
L 7 5 J 0 J C C 0 0 0 0 2 8 6 I C F I L T E R
(SWITCHES)
VOL_DW K0H1BB000094 TACTILE SWITCH
VOL_UP K0H1BB000094 TACTILE SWITCH
(RESISTORS)
R 2 E R J 2 G E J 3 0 3 3 0 k
R 3 D 0 G A 1 5 2 J A 0 2 1 1 . 5 k
R 4 D 0 G A 4 7 3 J A 0 2 1 4 7 k
R 6 D 0 G A 1 0 3 J A 0 2 1 1 0 k
R 7 D 0 G A 1 0 4 J A 0 2 1 1 0 0 k
R8 PQ4R18XJ3R3 3.3 S
R 9 E R J 2 G E J 3 0 3 3 0 k
R 2 1 D 0 G A 1 0 4 J A 0 2 1 1 0 0 k
R 2 2 D 0 G A 3 3 2 J A 0 1 5 3 . 3 k
R23 ERJ2GEYJ391 390 S
R24 ERJ2GEJ100 10 S
R 2 5 D 0 G A 2 2 2 J A 0 2 1 2 . 2 k
R 2 6 D 0 G A 3 3 2 J A 0 1 5 3 . 3 k
R 2 7 D 0 G A 2 2 2 J A 0 2 1 2 . 2 k
R 2 8 D 0 G A 2 2 2 J A 0 2 1 2 . 2 k
R 3 1 E R J 2 R K F 1 0 0 3 1 0 0 k
R 3 2 D 0 G A 1 0 4 J A 0 2 1 1 0 0 k
R 3 3 E R J 2 R K F 1 0 0 3 1 0 0 k
R34 ERJ2GEYJ391 390 S
R45 ERJ6RSJR10V 0.1
R50 D0GA151JA021 150
R51 D0GA151JA021 150
R 6 0 D 0 G A 2 2 2 J A 0 2 1 2 . 2 k
R 6 6 D 0 G A 1 0 3 J A 0 2 1 1 0 k
R 6 7 D 0 G A 1 0 3 J A 0 2 1 1 0 k
R 6 8 D 0 G A 1 0 3 J A 0 2 1 1 0 k
R 6 9 D 0 G A 1 0 3 J A 0 2 1 1 0 k
R70 D0GA470JA021 47
R73 D0GA330JA015 33
R74 D0GA330JA015 33
R80 D0GA101JA021 100
R806 ERJ2GEJ471 470 S
R807 ERJ2GEJ471 470 S
L8 ERJ2GEJ100 10 S
L9 ERJ2GE0R00 0 S
(CAPACITORS)
C1 EEE0JA221WP 220
C2 EEE0JA221WP 220
C3 EEE0JA221WP 220
C 4 E C U E 1 H 3 9 0 J C Q 3 9 p
C5 ECUE1A104KBQ 0.1
C6 ECUE1A104KBQ 0.1
C 9 E C U E 1 H 3 9 0 J C Q 3 9 p
C 1 0 E C U E 1 H 3 9 0 J C Q 3 9 p
C11 ECUE1A104KBQ 0.1
C12 PQCUV0J106KB 10 S
C13 ECUE1A104KBQ 0.1
C14 ECUV1C393KBV 0.039
C 1 5 E C U E 1 H 3 9 0 J C Q 3 9 p
C16 F1J0J2260002 22
C 1 7 E C U E 1 H 1 0 0 D C Q 1 0 p S
C 1 8 E C U E 1 H 1 0 0 D C Q 1 0 p S
C20 ECJ1VB0G106M 10 S
C21 ECUE0J105KBQ 1
Safety Ref.
No.
Part No. Part Name & Description Remarks
