Panasonic KX-TG4732B

95
KX-TG4732B/KX-TG4733B/KX-TG4734B/KX-TGA470B
16.5.2.3. LED Board Parts
16.5.3. Charger Unit
16.5.3.1. Cabinet and Electrical Parts
16.5.3.2. Main P.C. Board Parts
16.5.4. Accessories and Packing Materials
Note:
(*1) You can download and refer to the Operating
Instructions (Instruction book) on TSN Server.
16.5.4.1. KX-TG4732B
16.5.4.2. KX-TG4733B
C22 ECUE1A104KBQ 0.1
C23 ECUE1A104KBQ 0.1
C24 ECUE0J105KBQ 1
C25 ECUV1A225KBV 2.2 S
C26 ECJ1VB0G106M 10 S
C27 ECUE1H102KBQ 0.001 S
C29 ECUV1A105KBV 1
C30 ECUV1A105KBV 1
C31 ECJ1VB0G106M 10 S
C32 ECUE0J105KBQ 1
C33 ECUE1A104KBQ 0.1
C34 ECUE1H390JCQ 39p
C36 ECUE1A104KBQ 0.1
C37 ECJ1VB0G106M 10 S
C39 ECUE1H102KBQ 0.001 S
C40 ECUE1A104KBQ 0.1
C41 ECUE1A104KBQ 0.1
C42 ECUE1H102KBQ 0.001 S
C43 ECUE1A104KBQ 0.1
C44 ECUE0J105KBQ 1
C45 ECUE1A104KBQ 0.1
C46 ECUE1H100DCQ 10p S
C51 ECJ1VB0G106M 10 S
C52 ECUE1H100DCQ 10p S
C53 ECUE1H120JCQ 12p S
C56 ECUE0J105KBQ 1
C57 ECUE0J105KBQ 1
C58 ECUE0J105KBQ 1
C68 ECUE0J105KBQ 1
C69 ECUE1A104KBQ 0.1
C72 ECUE1H100DCQ 10p S
C73 ECUE1H100DCQ 10p S
C76 ECUE1H100DCQ 10p S
C77 ECUE1H100DCQ 10p S
C79 ECUE1H101JCQ 100p
C80 ECUV1C393KBV 0.039
C81 ECUE1H101JCQ 100p
C82 ECUE1H471KBQ 470p S
C83 ECUE1H100DCQ 10p S
C84 ECUE1H102KBQ 0.001 S
C87 ECUE1H102KBQ 0.001 S
C88 ECUE1H100DCQ 10p S
C89 ECUE1H100DCQ 10p S
C90 ECUE1A104KBQ 0.1
C91 ECUV1C105KBV 1
C92 ECUE0J105KBQ 1
C93 ECUV1C105KBV 1
C96 ECUE1H100DCQ 10p S
C97 ECUE1H100DCQ 10p S
C801 ECUV1H100DCV 10p
C802 F1G1H2R0A480 2p
C803 F1G1H1R3A480 1.3p
C804 F1G1H1R8A480 1.8p
C805 F1G1H2R4A480 2.4p
C806 F1G1H2R4A480 2.4p
C810 F1G1H2R5A480 2.5p
C811 ECUE1H101JCQ 100p S
C813 F1G1H1R6A480 1.6p
C820 F1G1H1R8A480 1.8p
C822 ECUE1H100DCQ 10p S
C825 ECUE1H100DCQ 10p S
C826 ECUE1H100DCQ 10p S
C863 F1G1H1R8A480 1.8p
C897 F1G1H240A557 24p
L809 F1G1H1R0A480 1p
(OTHERS)
MIC100 L0CBAY000053 MICROPHONE
E101 L5DYBYY00043 LIQUID CRYSTAL DISPLAY
(*3)
E102 PNHX1569Z COVER, DIFFUSION SHEET
E103 PNHX1518Z COVER, LCD SHEET
E104 PNHR1587Z TRANSPARENT PLATE, LCD PMMA-HB
E105 PNHR1586Z GUIDE, LCD ABS-HB
Safety Ref.
No.
Part No. Part Name & Description Remarks
E106 PQHG10729Z RUBBER PARTS, RECEIVER
E107 PNVE1002Z BATTERY TERMINAL ABS-HB
CN4 K2HD103D0001 JACK
F1 K5H252Y00002 FUSE
X1 H0J138500003 CRYSTAL OSCILLATOR (*2) S
Safety Ref.
No.
Part No. Part Name & Description Remarks
(LED)
WLED B3AFB0000370 LED
Safety Ref.
No.
Part No. Part Name & Description Remarks
200 PNLC1029ZB CHARGER UNIT ASS'Y
without NAME PLATE
(RTL)
200-1 PNKM1258Z1 CABINET BODY PS-HB
200-2 PNJT1105Z CHARGE TERMINAL
200-3 PNKF1150Z1 CABINET COVER PS-HB
200-4 PQHA10023Z RUBBER PARTS, FOOT
CUSHION
201 PNGT6446Z NAME PLATE
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB200 PNWPTGA470CH MAIN P.C.BOARD ASS'Y
(RTL)
(DIODE)
D1 B0ECKM000008 DIODE(SI)
(JACK)
J1 K2ECYB000001 JACK
(RESISTORS)
R1 ERJ14YJ1R0U 1
R2 ERJ14YJ1R0U 1
(FUSE)
F1 K5H302Y00003 FUSE
Safety Ref.
No.
Part No. Part Name & Description Remarks
A1 PNLV226Z AC ADAPTOR
A2 PQJA10075Z CORD, TELEPHONE
A3 PNQX5092Z INSTRUCTION BOOK (*1)
A4 PNKE1132Z1 HANGER, BELT CLIP ABS-HB
A5 PNKL1001Y1 STAND, WALL MOUNT ABS-HB
P1 PNPK3481001Z GIFT BOX
P2 PNPD1592Z CUSHION
Safety Ref.
No.
Part No. Part Name & Description Remarks
A101 PNLV226Z AC ADAPTOR
A102 PQJA10075Z CORD, TELEPHONE
A103 PNQX5092Z INSTRUCTION BOOK (*1)
Safety Ref.
No.
Part No. Part Name & Description Remarks
