Panasonic Lumix DC-G100 User Manual

106
4. Recording mode
Preview Mode
You can check the effects of aperture on the recording screen by
physically closing the aperture blades of the lens to the aperture value set
for actual recording.
In addition to the effects of aperture, you can check the effects of shutter
speed at the same time.
• Use the Fn button registered with [Preview] to operate. In default settings, this is
registered in the [Fn6].
For information about the Fn button, refer to page 294.
Press [Fn6].
• Each press of the button switches between the
effect preview screens.
Aperture effect: OFF
Shutter speed effect:
OFF
Aperture effect: ON
Shutter speed effect:
OFF
Aperture effect: ON
Shutter speed effect:
ON
• It is possible to record in preview mode.
• Range for shutter speed effect check is 8 seconds to 1/16000 of a second.
• Preview mode is not available when recording with [4K Pre-Burst].

Panasonic Lumix DC-G100 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3MP
Image Processor	Venus Engine
Built-in Flash	Yes
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 270 shots (CIPA)
Dimensions	115.6 x 82.5 x 54.2 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600 (expandable to 100-25600)
Autofocus System	Contrast AF
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	10 fps
Video Recording	4K/30p
Viewfinder	Electronic, 3.68 million dots
LCD Screen	3.0-inch, 1.84 million dots, free-angle touch screen
Battery	DMW-BLG10
Weight	Approximately 412 g (including battery and SD card)
Image Stabilization	5-Axis Hybrid I.S. (available in video recording)
