Panasonic Lumix DC-G100 User Manual

73
3. Basic Operations
Attaching the camera to a tripod grip
• Hold the camera and tripod grip tightly, and securely attach them so
that they do not drop.
• For removal, perform the steps backwards.
1
Set the Camera on/off switch to [OFF].
2
Loosen the camera stand.
● Turn the fastening knob in the direction of .
Camera stand
Fastening knob
3
Attach the camera to a tripod grip.
● Align the camera screw with the tripod mount
on the camera. Turn the camera stand in the
direction of
, and tighten it firmly.
4
Lock the camera stand.
● Adjust the orientation of the camera. Turn
the fastening knob in the direction of
, and
tighten it firmly.
• The camera stand can be tilted 40 degrees in any
direction.
5
Connect the camera with the
connection cable.
● Connect the connection cable
into the camera’s [USB/CHARGE]
socket.
• Check the direction of the terminals and
plug in/out straight holding onto the plug.
(Inserting at an angle can deform the
terminal and cause malfunction.)

Panasonic Lumix DC-G100 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3MP
Image Processor	Venus Engine
Built-in Flash	Yes
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 270 shots (CIPA)
Dimensions	115.6 x 82.5 x 54.2 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600 (expandable to 100-25600)
Autofocus System	Contrast AF
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	10 fps
Video Recording	4K/30p
Viewfinder	Electronic, 3.68 million dots
LCD Screen	3.0-inch, 1.84 million dots, free-angle touch screen
Battery	DMW-BLG10
Weight	Approximately 412 g (including battery and SD card)
Image Stabilization	5-Axis Hybrid I.S. (available in video recording)
