HDMI Output (Video) – Connecting HDMI Devices
458
Connecting HDMI Devices
≥Attaching the Cable Holder: 459
Getting started:
• Turn off the camera and the external monitor/external recorder.
Connect the camera and an external monitor or external
recorder with a commercially available HDMI cable.
(A) HDMI socket (Type A)
(B) External monitor
(C) External recorder
• Use an Ultra High Speed HDMI cable (Type A–Type A plug, up to 1.5 m (4.9 feet)
long).
• Check the direction of the terminals and plug in/out straight holding onto the plug.
(Inserting at an angle can deform the terminal and cause malfunction.)
• Do not connect the cable to the wrong terminals. This may cause a malfunction.
