Panasonic Lumix DMC-GX1

VQT3T96 (ENG)
10
Names and Functions of Main Parts
∫ Camera body
1 Sensor
2 Self-timer indicator/
AF Assist Lamp
3Flash
4 Lens fitting mark
5 Mount
6 Lens lock pin
7 Lens release button
8 Flash open button
9 Playback button
10 [AF/AE LOCK] button/
[Fn2] button
11 Rear dial
12 Touch screen/LCD monitor
13 [Fn1] button
14 [Q.MENU] button/
Delete/Return button
15 [MENU/SET] button
16 [AF/MF] button
17 Cursor buttons
3/ISO
1/WB (White Balance)
2/AF Mode button
4/[DRIVE MODE] button
This button in picture record mode will allow the user to select between the following
options.
Single/Burst/Auto bracket/Self-timer
18 [DISP.] button
4567
23
1
89
12 13 14 18
11
15 1716
10
