Recording
- 98 -
Displaying the MF Assist
This is displayed by moving the focus lever, rotating the focus ring, or touching the screen. (In
the Creative Control Mode [MINIATURE EFFECT], MF Assistance cannot be displayed by
touching the screen)
It can also be displayed by pressing 2 to display the setup screen for the enlarged area,
deciding the area to enlarge using the cursor button, and then pressing [MENU/SET].
It will switch to the setting screen for the enlarged area by pressing the cursor button when the
[DIRECT FOCUS AREA] in the [CUSTOM] menu is set to [ON].
Changing the display of the MF Assist
You can switch the magnification factor between approx. 4 times, 5 times and 10 times. In
the case of 4 times magnification, the central region is magnified. In the case of 5 and 10
times magnification, the whole screen is magnified.
You can change the magnification by touching [ ]/[ ] or rotating the rear dial.
Moving the enlarged area
The enlarged area can be moved by dragging the screen (P11), or pressing the cursor button.
The following will return the MF assistance to the original position.
When the [FOCUS MODE] is set to other than [MF]
Changing [ASPECT RATIO] or [PICTURE SIZE]
Turning the camera off
When [RESET] is touched in the setup screen for the enlarged area
Closing the MF Assist
It will close when the shutter button is pressed halfway.
It will also close by touching the [EXIT] on the screen or pressing [MENU/SET].
When displayed by moving the focus lever or rotating the focus ring, it is closed approximately
10 seconds after operations are stopped.
Note
The MF Assist is disabled when using the Digital Zoom or recording motion pictures.
MF Assist or MF guide may not display depending on the lens used, but you can display MF
Assist by direct operation of the camera, using the touch screen or a button.
MF ASSIST

Table of Contents

Other manuals for Panasonic Lumix DMC-GX1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX1 and is the answer not in the manual?

Panasonic Lumix DMC-GX1 Specifications

General IconGeneral
Megapixel16 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.68 MP
Image sensor size- \
Image formats supportedEXIF, JPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationLens
Still image resolution(s)3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Focal length range14 - 42 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Shoe mounting point typeHot shoe
Flash exposure correction±2EV (1/3 EV step)
Power source typeBattery
Maximum magnification0.34 x
Video resolutions640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Audio formats supportedAAC, LPCM
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
Magnification0.17 x
USB version2.0
HDMI connector typeMini
Product colorBlack, Silver
Scene modesChildren, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editingCrop, Resizing, Rotating
Photo effectsSepia
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
Battery typeH-PS14042
Battery voltage7.2 V
Battery capacity1010 mAh
Battery life (CIPA standard)310 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth39.4 mm
Width116.3 mm
Height67.8 mm
Weight318 g
Lens length63.6 mm
Lens diameter60.6 mm
Weight (including battery)413 g
