Panasonic Lumix DMC-GX1 User Manual

- 213 -
Others
[PICTURE IS DISPLAYED FOR 16:9 TV]/[PICTURE IS DISPLAYED FOR 4:3 TV]
•
Select [TV ASPECT] in the [SETUP] menu if you want to change the TV aspect. (P71)
• This message also appears when the USB connection cable is connected to the camera only.
In this case, connect the other end of the USB connection cable to a PC or a printer. (P190,
192)
[EDITING OPERATION CANNOT PROCEED AS INFORMATION PROCESSING IS
ONGOING.]
When a card with pictures deleted or file names changed using a PC or other device is
inserted into this unit, it will automatically retrieve new information and reconstruct the
burst groups. The currently retrieving information icon [ ] may be displayed in the
playback screen for long period of time when there are many image files, and deletion or
[PLAYBACK] Mode menu cannot be used during this time.
•
If you switch the power switch to [OFF] while information is being retrieved, the pictures for
which information was retrieved up to that point will be saved as a burst group. When you
switch on again, the information retrieval will restart from the same point.
[THIS BATTERY CANNOT BE USED]
•
Use a genuine Panasonic battery. If this message is displayed even when a genuine
Panasonic battery is used, contact the dealer or your nearest Service Center.
• If the battery terminal is dirty, clean it and remove any objects.

Panasonic Lumix DMC-GX1 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.68 MP
Image sensor size	- \
Image formats supported	EXIF, JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto/Manual
Auto Focus (AF) points	23
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
Maximum magnification	0.34 x
Video resolutions	640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Audio formats supported	AAC, LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.17 x
USB version	2.0
HDMI connector type	Mini
Product color	Black, Silver
Scene modes	Children, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editing	Crop, Resizing, Rotating
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Movie, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Battery type	H-PS14042
Battery voltage	7.2 V
Battery capacity	1010 mAh
Battery life (CIPA standard)	310 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope

Weight and Dimensions

Depth	39.4 mm
Width	116.3 mm
Height	67.8 mm
Weight	318 g
Lens length	63.6 mm
Lens diameter	60.6 mm
Weight (including battery)	413 g
