No.SX-DSV01676 (46-1)
R2 Motor Company, Matsushita Electric Industrial Co., Ltd.
1. Scope
This document specifies the servo drive for the AC servo system
manufactured and supplied by Motor Company, Matsushita Electric Industrial Co., Ltd.
2. Model No.
Notation of the model No. is as follows:
1 2 3 4 5 6 7 8 9 10 11 12
M A D D T 1 2 0 5 N
(Note) It means 100Mbps real-time communication.
Custom specifications
(Alphanumeric)
Interface
N: High-speed network type
(note)
Ratings of current detector
05: 5A
07: 7.5A
10: 10A
20: 20A
30: 30A
40: 40A
64: 64A
90: 90A
A2: 120A
Power supply voltage
1: Single phase, 100V
2: Single phase, 200V
3: 3-phase, 200V
5: Single-phase/3-phase, 200V
Frame
A: Type A
B: Type B
C: Type C
D: Type D
E: Type E
F: Type F
AC servo drive
A4 family
Max. current ratings of power
element
T1: 10A
T2: 15A
T3: 30A
T5: 50A
T7: 75A
TA: 100A
TB: 150A
To Next Page
