Panasonic PT-AE4000U

32 -
E
NGLISH
POSITION menu
Remote control Control panel
See “Navigating through the MENU” on page 16.
See “Menu list” on page 17.
H-POSITION
You can move the projected image horizontally for ne
adjustment.
Move
left
Move
right
V-POSITION
You can move the projected image vertically for ne
adjustment.
Move
down
Move
up
DOT CLOCK
If you have interference patterns of the projected
image, which is sometimes referred to as moire or
noise, you can minimize it by pressing ◄ ► to adjust
the clock frequency. (Available with RGB signal from
COMPUTER IN only)
NOTE:
If the projecting signal’s dot clock frequency is higher •
than 150 MHz, the adjustment may not make a
difference.
DOT CLOCK • needs to be adjusted before adjusting
the CLOCK PHASE.
CLOCK PHASE
If you require further adjustment for the same reason
as the DOT CLOCK adjustment, you can ne adjust the
timing of the clock. Press ◄ ► to adjust. (Available with
signals from COMPUTER IN/COMPONENT IN only)
NOTE:
If the projecting signal’s dot clock frequency is higher than •
150 MHz, the adjustment may not make a difference.
Available signals from • YP
B
P
R
:
1 125 (1 080)/60i, 1 125 (1 080)/50i, 1 125 (1 080)/60p,
1 125 (1 080)/50p, 1 125 (1 080)/24p, 750 (720)/60p,
750 (720)/50p.
ASPECT
You can switch the aspect ratio manually when needed.
Aspect ratio depend on signals
J
Press ◄ ► to cycle through the aspect ratio
options. The cycle pattern depends on the
connected signals.
VIDEO/
S-VIDEO
4:3
\
16:9
\
s16:9
\
JUST
\
ZOOM
\
AUTO
NTSC, NTSC 4.43, PAL-M, PAL60 signals
4:3
\
16:9
\
s16:9
\
14:9
\
ZOOM1
\
ZOOM2
\
JUST
PAL, PAL-N, SECAM signals
HDMI
4:3
\
16:9
\
s16:9
\
H-FIT
\
V-FIT
\
ZOOM
1 125 (1 080)/50i, 1 125 (1 080)/60i,
1 125 (1 080)/50p, 1 125 (1 080)/60p,
1 125 (1 080)/24p, 750 (720)/50p and
750 (720)/60p signals
4:3
\
16:9
\
s16:9
\
JUST
\
ZOOM
525p (480p) signal
4:3
\
16:9
\
s16:9
\
14:9
\
ZOOM1
\
ZOOM2
\
JUST
625p (576p) signal
COMPUTER
(RGB)/
COMPONENT
(YP
B
P
R
)
4:3
\
16:9
\
s16:9
\
14:9
\
ZOOM1
\
ZOOM2
\
JUST
625i (576i), 625p (576p) signals
4:3
\
16:9
\
s16:9
\
JUST
\
ZOOM
525i (480i), 525p (480p) signals
4:3
\
16:9
\
s16:9
\
H-FIT
\
V-FIT
\
ZOOM
1 125 (1 080)/50i, 1 125 (1 080)/60i,
1 125 (1 080)/50p, 1 125 (1 080)/60p,
1 125 (1 080)/24p, 750 (720)/50p,
750 (720)/60p signals
