The figure below shows on-screen displays for any desired setting, starting with the MAIN MENU, and ending with
its sub-menu.
Normal screen
LENS
LENSFOCUS :＋−
LENSSHIFT :
EXIT : MENU
POSITION
SHIFT
SIZE
BLK
CLOCKPHASE
INPUTRESOLUTION
CLAMPPOSITION
KEYSTONE
EDGEBLENDING
MENU :
SUBMENU : ENTER
EXIT : MENU
LENS (Lens adjustment mode)
POSITION (Screen position
adjustment mode)
PICTURE (Picture adjustment mode)
MENU screen
On-screen menu operation guide
•[On-screen displays such as the input
signal type will appear when the input
signal is changed. (The display will
disappear automatically.)]
Contents of menu screen
MENU

AUTO SETUP
LENS
PICTURE
POSITION
OPTION
SIGNAL LIST
TESTPATTERN





 MENU：
▲
▼

 START：ENTER
 EXIT：MENU 
Screen
name
Selection
items
●The color of a
selected item
changes
Operation
guide
●Displayed conte-
nts depends on
a selected item
Display of operation buttons

●Displayed buttons depends
on a selected item
Display of operation contents
MENU
START
SUBMENU 
SELECT
CHANGE
EXIT
Selects from the items on screen 
Starts the automatic adjustment 
Advances to the next screen 
Selects setting values and others 
Changes 
Return to the previous screen
SELECT：

▼
▼
OPTION
ID : nn
SETTING :＊＊＊＊＊＊＊
LAMP RUNTIME
NORMAL :nnnnnh
HIGH :nnnnnh
REMAIN :nnnnnh
SET RUNTIME :nnnnnh
LAMP POWER :＊＊＊＊＊＊
CONTRASTMODE:＊＊＊＊
MENU :
SELECT :
EXIT : MENU
OPTION (Miscellaneous
setting mode)
SIGNAL LIST
NAME INPUT SS
nn:＊＊＊＊＊＊＊＊＊＊＊＊1 n−n
nn:＊＊＊＊＊＊＊＊＊＊＊＊2 n−n
nn:＊＊＊＊＊＊＊＊＊＊＊＊3 n−n
nn:＊＊＊＊＊＊＊＊＊＊＊＊1 n−n
nn:＊＊＊＊＊＊＊＊＊＊＊＊2 n−n
nn:
nn:〈NO ENTRY〉 − −
nn:〈NO ENTRY〉 − −
NEXT PAGE
DELETE : STD
SELECT :
STATUS : ENTER
EXIT : MENU
SIGNAL LIST (Registered signal list)
RGB
INPUT:n
NAME:＊＊＊＊
ID:nnn
S.S.− No:nn− nn
MENU
AUTO SETUP
LENS
POSITION
OPTION
SIGNAL LIST
TEST PATTERN
SELECT :
MENU :
START : ENTER
EXIT : MENU
COLOR TEMP : ＊＊＊＊
BRIGHT :nnn
CONTRAST :nnn
COLOR :nnn
TINT :nnn
SHARPNESSH :nnn
SHARPNESSV :nnn
NR :＊＊＊＊＊
GAMMA :2.2
MENU :
SELECT :
EXIT : MENU
ENGLISH
