Panasonic PT-D9510E

72
ENGLISH



ID List
ID
Code specified
ALL 00h
1 01h
2 02h
3 03h
4 04h
5 05h
6 06h
7 07h
8 08h
9 09h
10 0Ah
11 0Bh
ID
Code specified
12 0Ch
13 0Dh
14 0Eh
15 0Fh
16 10h
17 11h
18 12h
19 13h
20 14h
21 15h
22 16h
23 17h
ID
Code specified
24 18h
25 19h
26 1Ah
27 1Bh
28 1Ch
29 1Dh
30 1Eh
31 1Fh
32 20h
33 21h
34 22h
35 23h
ID
Code specified
36 24h
37 25h
38 26h
39 27h
40 28h
41 29h
42 2Ah
43 2Bh
44 2Ch
45 2Dh
46 2Eh
47 2Fh
ID
Code specified
48 30h
49 31h
50 32h
51 33h
52 34h
53 35h
54 36h
55 37h
56 38h
57 39h
58 3Ah
59 3Bh
ID
Code specified
60 3Ch
61 3Dh
62 3Eh
63 3Fh
64 40h
Receive (PC DLP
TM
based projector)：
STX(02h) ID NO (01h) INPUT 1(0Ah) ETX(03h)
Send (PC DLP
TM
based projector)：
STX(02h) ID NO (01h) INPUT 1(0Ah) ETX(03h)

Example: Send a INPUT 1 command to the DLP
TM
based projector with ID1.
Receive (PC DLP
TM
based projector)：
STX(02h) ID NO (00h) PICTURE MUTE(91h) ETX(03h)
Send (PC DLP
TM
based projector)：
STX(02h) ID NO (1byte) PICTURE MUTE(91h) ETX(03h)
• Send a PICTURE MUTE command to all the DLP
TM
based projectors.
•The ID No. is that of the DLP
TM
based projector whose VPS SYSTEM is set up for MASTER.

IDCode

 specified 
GROUPA80h
GROUPB81h
GROUPC82h
GROUPD83h
GROUPE84h






ID
Code

 specified 
GROUPF85h
GROUPG86h
GROUPH87h
GROUPI88h
GROUPJ89h

ID
Code

 specified 
GROUPK8Ah
GROUPL8Bh
GROUPM8Ch
GROUPN8Dh
GROUPO8Eh

ID
Code

 specified 
GROUPP8Fh
GROUPQ90h
GROUPR91h
GROUPS92h
GROUPT93h

ID
Code

 specified 
GROUPU94h
GROUPV95h
GROUPW96h
GROUPX97h
GROUPY98h

ID
Code

 specified 
GROUPZ99h



Receive (PC DLP
TM
based projector)：
STX(02h) ID NO (80h) INPUT 2(0Bh) ETX(03h)
Send (PC DLP
TM
based projector)：
STX(02h) ID NO (1byte) INPUT 2(0Bh) ETX(03h)
• When transferring commands for INPUT 2 to the DLP
TM
based projector in GROUP A:
•The ID NO transferred will be the GROUP A DLP
TM
based projector ID set as the MASTER by the GROUP SYSTEM.

