Chapter 4 Settings — [PROJECTOR SETUP] menu
180 - ENGLISH
f You can set the program from No.1 to No.7. “- - -” indicates that the program number has not been set.
How to set a program
Set up to 16 commands to each program.
1) Press as to select [SCHEDULE].
2) Press qw to select [ON], and press the <ENTER> button.
f The [SCHEDULE] screen is displayed.
3) Press as to select [PROGRAM EDIT].
4) Press qw to select a program number, and press the <ENTER> button.
5) Press as to select a command number, and press the <ENTER> button.
f You can change the page using qw.
6) Press asqw to select [TIME], and press the <ENTER> button.
f The projector is in the adjustment mode (the time is blinking).
7) Press qw to select “hour” or “minute”, and press as or the number (<0> - <9>) buttons to set a
time, and then press the <ENTER> button.
8) Press asqw to select [COMMAND].
9) Press the <ENTER> button.
f The [COMMAND] detailed screen is displayed.
10) Press as to select a [COMMAND].
f For [COMMAND] which requires detailed settings, the items of the detailed settings will switch each time
you press qw.
f When [INPUT] is selected, press the <ENTER> button, and then press asqw to select the input to be
set.
[COMMAND]
Detailed settings of
[COMMAND]
Description
[POWER ON] ― Switches on the projector.
[STANDBY] ― Enters standby.
[SHUTTER]
[OPEN] Disables the shutter function (shutter: open).
[CLOSE] Enables the shutter function (shutter: closed).
[INPUT]
[SDI1] Switches the input to SDI1.
[SDI2] Switches the input to SDI2.
[SDI3] Switches the input to SDI3.
[SDI4] Switches the input to SDI4.
[DIGITAL LINK] Switches the input to DIGITAL LINK.
[HDMI1 [SLOT1]]
*1
Switches the input to HDMI1 of the Interface Board.
[HDMI2 [SLOT1]]
*1
Switches the input to HDMI2 of the Interface Board.
[HDMI3 [SLOT2]]
*2
Switches the input to HDMI3 of the Interface Board.
[HDMI4 [SLOT2]]
*2
Switches the input to HDMI4 of the Interface Board.
[DVI-D1 [SLOT1]]
*1
Switches the input to DVI-D1 of the Interface Board.
[DVI-D2 [SLOT1]]
*1
Switches the input to DVI-D2 of the Interface Board.
[DVI-D3 [SLOT2]]
*2
Switches the input to DVI-D3 of the Interface Board.
[DVI-D4 [SLOT2]]
*2
Switches the input to DVI-D4 of the Interface Board.
[SDI1 [SLOT1]]
*1
Switches the input to SDI1 of the Interface Board.
[SDI2 [SLOT1]]
*1
Switches the input to SDI2 of the Interface Board.
[SDI3 [SLOT1]]
*3
Switches the input to SDI3 of the Interface Board.
[SDI4 [SLOT1]]
*3
Switches the input to SDI4 of the Interface Board.
[SDI1 [SLOT2]]
*4
Switches the input to SDI1 of the Interface Board.
[SDI2 [SLOT2]]
*4
Switches the input to SDI2 of the Interface Board.
[SDI3 [SLOT2]]
*2
Switches the input to SDI3 of the Interface Board.
[SDI4 [SLOT2]]
*2
Switches the input to SDI4 of the Interface Board.
[INPUT1] - [INPUT10]
*5
Switches the input to DIGITAL LINK, and switches the input of the
Panasonic twisted-pair-cable transmitter to the specied input.
To Next Page
