Chapter 4 Settings — [PROJECTOR SETUP] menu
164 - ENGLISH
[LINKED]
All the projectors are correctly connected, and correctly set. They are in the condition that the contrast
synchronization function or the shutter synchronization function can be used.
[NO LINK]
The projectors are not correctly connected, or not correctly set. Check the cable connection status
and the projector setting for each projector that is linked.
5) Press as to select [SHUTTER SYNC].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] Select this item when the shutter synchronization function is not used.
[ON] Select this item when the shutter synchronization function is used.
Note
f The shutter synchronization function will operate when all of the following conditions are fullled.
g All the projectors to be linked are connected in a loop with the daisy chain connection. (Maximum 64 projectors)
g [MODE] on only one projector that is linked is set to [MASTER], and [MODE] on all other projectors are set to [SLAVE].
g [SHUTTER SYNC] on the projectors to perform the shutter synchronization is set to [ON].
f It is possible to set [SHUTTER SYNC] to [OFF] for the projectors that are linked but not to synchronize.
f The shutter operation by the shutter synchronization function will follow the setting of the [DISPLAY OPTION] menu → [SHUTTER
SETTING] on the projector that [MODE] is set to [MASTER].
f When the input signal to each linked projector is not synchronized, the timing of the shutter operation between the projectors may shift up to
1 frame while using the shutter synchronization function.
f The shutter function of the projector with [MODE] set to [SLAVE] can be operated individually. The shutter operation at this time will follow
the setting of the [DISPLAY OPTION] menu → [SHUTTER SETTING] set in that projector.
[RS-232C]
Set the communication conditions of the <SERIAL IN>/<SERIAL OUT> terminals. For details on the connection
method for RS‑232C communication, refer to “<SERIAL IN>/<SERIAL OUT> terminal” (x page 228).
Setting the communication condition of the <SERIAL IN> terminal
1) Press as to select [RS-232C].
2) Press the <ENTER> button.
f The [RS-232C] screen is displayed.
3) Press as to select [INPUT SELECT].
4) Press qw to switch the item.
[PROJECTOR] Performs the RS-232C communication with the <SERIAL IN> terminal of the projector.
[DIGITAL LINK]
Performs the RS‑232C communication via the optional DIGITAL LINK output supported device (Model
No.: ET-YFB100G, ET-YFB200G) and the <DIGITAL LINK/LAN> terminal.
5) Press as to select [(IN) BAUDRATE].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[9600]
Select the proper speed.[19200]
[38400]
7) Press as to select [(IN) PARITY].
8) Press qw to switch the item.
f The items will switch each time you press the button.
[NONE]
Select the parity condition.[EVEN]
[ODD]
