Panasonic PT-VW330U - Contrast, Brightness, and Color Settings; Tint and Color Temperature Adjustment

Image adjust
ENGLISH -
45
Settings
Select [Image adjust] from the Main Menu (see
“Navigating through the menu” on page 36),
then select the item from the sub-menu.
Remote Control
Control Panel
Contrast
Press ▲▼ to select [Contrast].1 )
Press the <SELECT> button to display 2 )
the adjustment dialog box.
Press ◄► to adjust the setting value.3 )
Operation Adjustment
Adjustment
range
Press ►. increase the contrast
Maximum
value 63
Press ◄.
decrease the
contrast
Minimum
value 0
Brightness
Press ▲▼ to select [Brightness].1 )
Press the <SELECT> button to display 2 )
the adjustment dialog box.
Press ◄► to adjust the setting value.3 )
Operation Adjustment
Adjustment
range
Press ►.
increase the
brightness
Maximum
value 63
Press ◄.
decrease the
brightness
Minimum
value 0
Color
Press ▲▼ to select [Color].1 )
Press the <SELECT> button to display 2 )
the adjustment dialog box.
Press ◄► to adjust the setting value.3 )
Operation Adjustment
Adjustment
range
Press ►.
increase the
intensity of the color
Maximum
value 63
Press ◄.
decrease the
intensity of the color
Minimum
value 0
Attention
When input video signal to the projector, Color will be
z
available.
Tint
Press ▲▼ to select [Tint].1 )
Press the <SELECT> button to display 2 )
the adjustment dialog box.
Press ◄► to adjust the tint value to 3 )
get a proper color balance.
Adjustments can be made between
z
0 and 15.
Attention
When you select NTSC or NTSC4.43 in System menu
z
under Video input signal, Tint will be available.
Color temp.
Press ▲▼ to select [Color temp.].1 )
Press the <SELECT> button to display 2 )
the adjustment dialog box.
Press ◄► to select the desired Color 3 )
temp. level.
You can select the desired Color temp. from
z
(XLow, Low, Mid or High).
Image adjust
