Panasonic PT-VZ575N

Mode
Display resolution
(dots)
Scanning frequency
Dot clock
frequency
(MHz)
Format
PnP*
1
H (kHz) V (Hz)
COMPUTER1 /
COMPUTER2
HDMI /
DIGITAL
LINK
1280 x 720
1 280 x 720 37.1 49.8 60.5 R/H
― ―
1 280 x 720 44.8 59.9 74.5 R/H
― ―
1280 x 768
1 280 x 768 60.3 74.9 102.3 R/H
― ―
1 280 x 768 68.6 84.8 117.5 R/H
― ―
1280 x 800
1 280 x 800 41.3 50.0 68.0 R/H
― ―
1 280 x 800 49.7 59.8 83.5 R/H
l*
5
l*
5
1 280 x 800 62.8 74.9 106.5 R/H
― ―
1 280 x 800 71.6 84.9 122.5 R/H
― ―
1280 x 960 1 280 x 960 60.0 60.0 108.0 R/H
― ―
SXGA
1 280 x 1 024 64.0 60.0 108.0 R/H
― ―
1 280 x 1 024 80.0 75.0 135.0 R/H
― ―
1 280 x 1 024 91.1 85.0 157.5 R/H
― ―
1366 x 768
1 366 x 768 39.6 49.9 69.0 R/H
― ―
1 366 x 768 47.7 59.8 85.5 R/H
― ―
1400 x 1050
1 400 x 1 050 65.2 60.0 122.6 R/H
― ―
1 400 x 1 050 65.3 60.0 121.8 R/H
― ―
1 400 x 1 050 82.2 75.0 156.0 R/H
― ―
1440 x 900 1 440 x 900 55.9 60.0 106.5 R/H
― ―
1600 x 900
1 600 x 900 46.3 50.0 97.0 R/H
― ―
1 600 x 900 55.9 60.0 119.0 R/H
― ―
UXGA 1 600 x 1 200 75.0 60.0 162.0 R/H
l l
1680 x 1050
1 680 x 1 050 54.1 50.0 119.5 R/H
― ―
1 680 x 1 050 65.3 60.0 146.3 R/H
― ―
1920 x 1080
1 920 x 1 080 55.6 49.9 141.5 R/H
― ―
1 920 x 1 080
*4
66.6 59.9 138.5 R/H
― ―
1 920 x 1 080
*6
67.2 60.0 173.0 R
― ―
WUXGA
1 920 x 1 200 61.8 49.9 158.3 R/H
― ―
1 920 x 1 200
*4
74.0 60.0 154.0 R/H
l*
7
l*
7
1 920 x 1 200
*6
74.6 59.9 193.3 R
― ―
*1 Where marked "l" signals indicates in Plug and Play is compatible with EDID of projector. Unmarked signals in Plug and
Play may also be compliant if input terminals are written in the format list. Where Plug and Play is unmarked and nothing is
written in the format list, difculties in projecting image may occur even when computer and projector appear to have same
resolution.
*2 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*3 When a 1125 (1035)/60i signal was input, it is displayed as a 1125 (1080)/60i signal.
*4 VESA CVT-RB (Reduced Blanking)-compliant
*5 Only for PT-VW535N
*6 Samples the pixels in the image processing circuit and displays the image.
*7 Only for PT-VZ575N
Note
f The number of display dots is 1 920 x 1 200 for the PT-VZ575N, 1 280 x 800 for the PT-VW535N and 1 024 x 768 for the
PT-VX605N.
A signal with a different resolution will be projected after converting the resolution to match the projector display.
f “i” added to the resolution value indicates an interlaced signal.
f When interlaced signals are connected, icker may occur on the projected image.
f Even the above signals exist, some image signals that recorded in special method may not be displayed.
ENGLISH - 143
Chapter 7 Appendix - Technical Information
