Panasonic PT-VZ580

Projection distance
An error of ± 5% may occur to the projection distance as described.
Also, it is corrected to become smaller than the specied image size when [SCREEN ADJUSTMENT] is used.
For PT-VZ580D and PT-VZ580T
(Unit: m)
Projection
size
16:10 aspect ratio 16:9 aspect ratio 4:3 aspect ratio
Screen
diagonal
(SD)
Minimum
distance
(LW)
Maximum
distance
(LT)
Distance from
the lens center
to the image
lower end (H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Distance from
the lens center
to the image
lower end (H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Distance from
the lens center
to the image
lower end (H)
0.76 (30") 0.68 1.12 0.022 ~ 0.201 0.70 1.15 0.002 ~ 0.186 0.78 1.27 0.025 ~ 0.228
1.02 (40") 0.93 1.51 0.030 ~ 0.270 0.95 1.55 0.003 ~ 0.250 1.05 1.71 0.034 ~ 0.306
1.27 (50") 1.16 1.89 0.037 ~ 0.337 1.19 1.94 0.004 ~ 0.311 1.32 2.14 0.042 ~ 0.381
1.52 (60") 1.39 2.26 0.045 ~ 0.403 1.43 2.33 0.005 ~ 0.372 1.58 2.57 0.051 ~ 0.456
1.78 (70") 1.64 2.66 0.052 ~ 0.472 1.69 2.73 0.005 ~ 0.436 1.86 3.01 0.059 ~ 0.534
2.03 (80") 1.87 3.03 0.060 ~ 0.538 1.93 3.12 0.006 ~ 0.497 2.12 3.44 0.068 ~ 0.609
2.29 (90") 2.12 3.43 0.067 ~ 0.607 2.18 3.52 0.007 ~ 0.561 2.40 3.88 0.076 ~ 0.687
2.54 (100") 2.35 3.80 0.075 ~ 0.673 2.42 3.91 0.008 ~ 0.622 2.67 4.31 0.085 ~ 0.762
3.05 (120") 2.83 4.57 0.090 ~ 0.808 2.91 4.70 0.009 ~ 0.747 3.21 5.18 0.102 ~ 0.915
3.81 (150") 3.54 5.72 0.112 ~ 1.010 3.64 5.88 0.012 ~ 0.933 4.01 6.48 0.127 ~ 1.143
5.08 (200") 4.73 7.64 0.150 ~ 1.346 4.86 7.85 0.015 ~ 1.245 5.36 8.65 0.169 ~ 1.524
6.35 (250") 5.92 9.56 0.187 ~ 1.683 6.09 9.83 0.019 ~ 1.556 6.71 10.83 0.212 ~ 1.905
7.62 (300") 7.11 11.48 0.224 ~ 2.019 7.31 11.80 0.023 ~ 1.867 8.05 13.00 0.254 ~ 2.286
For PT-VW540D and PT-VW540T
(Unit: m)
Projection
size
16:10 aspect ratio 16:9 aspect ratio 4:3 aspect ratio
Screen
diagonal
(SD)
Minimum
distance
(LW)
Maximum
distance
(LT)
Distance from
the lens center
to the image
lower end (H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Distance from
the lens center to
the image lower
end (H)
Minimum
distance
(LW)
Maximum
distance
(LT)
Distance from
the lens center
to the image
lower end (H)
0.76 (30") 0.68 1.12 0.022 ~ 0.201 0.70 1.15 0.002 ~ 0.186 0.77 1.27 0.025 ~ 0.228
1.02 (40") 0.92 1.51 0.030 ~ 0.270 0.94 1.55 0.003 ~ 0.250 1.04 1.71 0.034 ~ 0.306
1.27 (50") 1.15 1.88 0.037 ~ 0.337 1.18 1.94 0.004 ~ 0.311 1.31 2.14 0.042 ~ 0.381
1.52 (60") 1.38 2.26 0.045 ~ 0.403 1.42 2.32 0.005 ~ 0.372 1.57 2.56 0.051 ~ 0.456
1.78 (70") 1.62 2.65 0.052 ~ 0.472 1.67 2.72 0.005 ~ 0.436 1.84 3.00 0.059 ~ 0.534
2.03 (80") 1.86 3.03 0.060 ~ 0.538 1.91 3.11 0.006 ~ 0.497 2.10 3.43 0.068 ~ 0.609
2.29 (90") 2.10 3.42 0.067 ~ 0.607 2.16 3.51 0.007 ~ 0.561 2.38 3.87 0.076 ~ 0.687
2.54 (100") 2.33 3.79 0.075 ~ 0.673 2.39 3.90 0.008 ~ 0.622 2.64 4.30 0.085 ~ 0.762
3.05 (120") 2.80 4.56 0.090 ~ 0.808 2.88 4.69 0.009 ~ 0.747 3.18 5.17 0.102 ~ 0.915
3.81 (150") 3.51 5.70 0.112 ~ 1.010 3.61 5.86 0.012 ~ 0.933 3.98 6.46 0.127 ~ 1.143
5.08 (200") 4.69 7.61 0.150 ~ 1.346 4.82 7.83 0.015 ~ 1.245 5.31 8.62 0.169 ~ 1.524
6.35 (250") 5.87 9.52 0.187 ~ 1.683 6.03 9.79 0.019 ~ 1.556 6.65 10.78 0.212 ~ 1.905
7.62 (300") 7.05 11.43 0.224 ~ 2.019 7.24 11.75 0.023 ~ 1.867 7.98 12.95 0.254 ~ 2.286
ENGLISH - 29
Chapter 2 Getting Started - Setting up
