10
IMPORTANT ........................ 2
Please Read Before Starting
1. GENERAL ...................... 11
1-1. Tools Required for Installation (not
supplied)
1-2. Accessories Supplied with Unit
1-3. Type of Copper Tube and Insulation
Material
1-4. Additional Materials Required for
Installation
2. SELECTING THE INSTALLATION
SITE ........................... 13
2-1. Indoor Unit
3. HOW TO INSTALL THE INDOOR
UNIT .......................... 14
3-1. Preparation for Suspending
3-2. Suspending the Indoor Unit
3-3. Placing the Unit Inside the Ceiling
3-4. How to Process Tubing
3-5. Installing the Drain Pipe
3-6. Important Note for Wiring 4-Way Cassette
60 × 60 Type
4. ELECTRICAL WIRING ............ 21
4-1. General Precautions on Wiring
4-2. Wire Length and Wire Diameter for Power
Supply System
4-3. Wiring System Diagrams
5. HOW TO PROCESS TUBING ....... 34
5-1. Connecting the Refrigerant Tubing
5-2. Connecting Tubing Between Indoor and
Outdoor Units
5-3. Insulating the Refrigerant Tubing
5-4. Taping the Tubes
5-5. Finishing the Installation
6. HOW TO INSTALL THE TIMER REMOTE
CONTROLLER OR HIGH-SPEC WIRED
REMOTE CONTROLLER (OPTIONAL
PART) ......................... 38
NOTE
Refer to the Installation Instructions attached
to the optional Timer Remote Controller or
optional High-spec Wired Remote Controller.
7. HOW TO INSTALL THE PANEL FOR
CASSETTE ..................... 39
7-1. Preparation for Panel for Cassette
Installation
7-2. How to Install the Panel for Cassette
7-3. Others
8. HOW TO INSTALL WIRELESS REMOTE
CONTROLLER .................. 46
NOTE
Refer to the Installation Instructions attached to
the optional Wireless Remote Controller.
9. TEST RUN ...................... 47
9-1. Precautions
9-2. Test Run Procedure
9-3. Items to Check Before the Test Run
9-4. Check the Combination (wiring) of Indoor
and Outdoor Units
9-5. Address Setting : 2-LINE CONNECTION
9-6. Address Setting : 3-LINE CONNECTION
9-7. Auto Address Setting Using the Remote
Controller
9-8. How to Set Refrigerant System Address
(Only outdoor PZ2 and PZH2 series)
9-9. Checking the Indoor Unit Addresses
9-10. Test Run Using the Remote Controller
9-11. Main-Sub Remote Controller Contro
l
10. CHECKLIST AFTER INSTALLATION
WORK ......................... 70
11. APPENDIX .....................71
■
Care and Cleaning
■
Troubleshooting
■
Tips for Energy Saving
Important Information Regarding
The Refrigerant Used ............ 74
NOTE
Refer to the Installation Instructions attached to
the outdoor unit.
12. CHECK OF DENSITY LIMIT ........ 75
SUPPLEMENT ..................... 76
INSTALLATION INSTRUCTION
SUPPLEMENT ..................... 79
Page Page
CONTENTS
01_330918_EU_Eng.indb 10 2021/9/9 11:26:42
