148
46 RMCX1007 USB GROUND
SPRING
1
48 RMN0941 AC INLET HOLDER 1
51 RXQX1033-2 MAIN PCB SHIELD
PLATE UNIT
1
52 REEX1120 8P FFC WIRE
(MIC-MAIN)
1
54 RMQX1025-J GASKET (TOP) 1
55 RMQX1037-J GASKET (BOTTOM) 1
58 REXX1111 1P GROUND WIRE
(MIC)
1
59 RMNX1031-1 MAIN PC SHEET 2
60 REXX1120 1P WHITE WIRE
(SMPS-VOLTAGE
SELECTOR)
1
61 REXX1121 1P BLUE WIRE
(SMPS-VOLTAGE
SELECTOR)
1
62 RMQX1052-1L GASKET 1
69 RFKZPT980GAK 22P FFC (FL-
MAIN)
1
70 RFKZPT480EBK 15P FFC (iPod-
MAIN)
1
TRAVERSE DECK
401 RAEX1022Z-V TRAVERSE UNIT 1
PACKING MATERI-
ALS
P1 RPGX3145 PACKING CASE 1
P2 RPNX1026 POLYFOAM 1
P3 RPFX1012 MIRAMAT SHEET 1
ACCESSORIES
A1 N2QAYB000516 REMOTE CONTROL 1
A1-1 RKK-PT470EBK R/C BATTERY
COVER
1
A2 K2CQ2CA00007 AC CORD 1
A3 RQTX1129-M O/I BOOK (Sp) 1
A4 K2KA2BA00001 VIDEO CABLE 1
A5 RSAX0002 FM INDOOR
ANTENNA
1
A6 K2DAYYY00002 AC PLUG ADAPTOR 1
A9 K1HA19DA0007 HDMI CABLE 1
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
To Next Page
