Panasonic SA-PT480PH

92
11.9. D-Amp P.C.B. (1/2)
REF NO.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 11.5 3.3 3.3 1.6 3.1 1.6 1.1 0 0 3.5 3.5 0 0 1.5 3.1 1.5 11.6 11.4 11.5 0
STANDBY 11.5 3.3 3.3 1.6 3.1 1.6 1.1 0 0 3.5 3.5 0 0 1.5 3.1 1.5 11.6 11.4 11.5 0
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
CD PLAY 42.4 0 0 0 0 42.4 0 0 42.4 0 0 0 0 42.4 0 11.4
STANDBY 42.4 0 0 0 0 42.4 0 0 42.4 0 0 0 0 42.4 0 11.4
REF NO.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 11.5 3.2 3.3 1.6 3.2 1.6 1.1 0 0 3.2 0 0 3.2 1.6 3.2 1.6 11.6 11.5 11.5 0
STANDBY 11.5 3.2 3.3 1.6 3.2 1.6 1.1 0 0 3.2 0 0 3.2 1.6 3.2 1.6 11.6 11.5 11.5 0
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
CD PLAY 42.4 0 0 0 0 42.4 0 0 42.4 0 0 0 0 42.4 0 11.5
STANDBY 42.4 0 0 0 0 42.4 0 0 42.4 0 0 0 0 42.4 0 11.5
REF NO.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 1.7 3.2 0 0 0.8 0.9 0 1.6 3.2 3.1 3.1 0 0 1.1 1.8 3.2 3.2 3.2 1.5 1.5
STANDBY 1.7 3.2 0 0 0.8 0.9 0 1.6 3.2 3.1 3.1 0 0 1.1 1.8 3.2 3.2 3.2 1.5 1.5
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
CD PLAY 0 0 0 0 0.6 1.2 0 0 0 1.8 3.1 3.1 1.6 1.6 1.5 1.5 1.5 1.5
STANDBY 0 0 0 0 0.6 1.2 0 0 0 1.8 3.1 3.1 1.6 1.6 1.5 1.5 1.5 1.5
REF NO.
MODE 12345
CD PLAY 13.1 13.1 0 11.6 1.1
STANDBY 13.1 13.1 0 11.6 1.1
REF NO.
MODE 12345
CD PLAY 3.2 3.2 0 0 0
STANDBY 3.2 3.2 0 0 0
REF NO.
MODE 12345
CD PLAY 3.2 3.2 0 3.2 3.2
STANDBY 3.2 3.2 0 3.2 3.2
REF NO.
MODE 123456
CD PLAY 1.5 0 1.5 1.6 3.1 1.6
STANDBY 1.5 0 1.5 1.6 3.1 1.6
IC5404
SA-PT480PH D-AMP P.C.B.
IC5100
IC5402
IC5301
IC5400
IC5401
IC5100
IC5200
IC5200
IC5301
