Panasonic SA-PT480PH

93
11.10. D-Amp P.C.B. (2/2)
11.11. SMPS P.C.B.
11.12. Power P.C.B.
REF NO.
MODE 1 2 3 4 5
CD PLAY 3.2 3.2 0 3.2 3.1
STANDBY 3.2 3.2 0 3.2 3.1
REF NO.
MODE E C B E C B E C B E C B E C B
CD PLAY 12.0 18.0 12.0 18.0 12.0 0 0 0 5.0 0 2.9 12.0 0 7.5 0.7
STANDBY 12.0 18.0 12.0 18.0 12.0 0 0 0 5.0 0 2.9 12.0 0 7.5 0.7
REF NO.
MODE E C B E C B E C B E C B E C B
CD PLAY 0 3.7 12.0 0 0 0 0 0 0 0 0 42.3 42.4 42.3 0
STANDBY 0 3.7 12.0 0 0 0 0 0 0 0 0 42.3 42.4 42.3 0
REF NO.
MODE E C B E C B E C B
CD PLAY 0 0 0 0 0 0 12.0 0 5.0
STANDBY 0 0 0 0 0.1 5.0 12.0 0 5.0
IC5405
Q5413
Q5414
Q5405 Q5408 Q5409 Q5412
Q5404
SA-PT480PH D-AMP P.C.B.
Q5400 Q5401 Q5402 Q5403
QR5401QR5400
REF NO.
MODE 1234567
CD PLAY 165.0 0 0 19.0 0.1 1.5 0.4
STANDBY 165.0 0 0 19.0 0.1 1.5 0.4
REF NO.
MODE 12345678
CD PLAY 6.0 0.8 2.4 12.3 165.0 0 0 0
STANDBY 6.0 0.8 2.4 12.3 165.0 0 0 0
REF NO.
MODE 1 2 3
CD PLAY 18.3 2.5 0
STANDBY 18.3 2.5 0
REF NO.
MODE 1234
CD PLAY 0 0 3.8 2.3
STANDBY 0 0 3.8 2.3
REF NO.
MODE E C B E C B E C B E C B E C B
CD PLAY -10.3 -9.9 -10.2 0 0.6 0 0 1.9 0.4 0 0.1 0.7 0 0 13.0
STANDBY -10.3 -9.9 -10.2 0 0.6 0 0 1.9 0.4 0 0.1 0.7 0 0 13.0
SA-PT480PH SMPS P.C.B.
IC5701
IC5799
IC5801
IC5899
Q5720 Q5863 Q5898
Q5899
QR5862
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 1.7 2.5 2.0 1.0 1.6 0 0 18.0 11.2 14.9 14.3 18.0 16.5 0 15.8 1.6 1.0 2.0 2.4 2.5
STANDBY 1.7 2.5 2.0 1.0 1.6 0 0 18.0 11.2 14.9 14.3 18.0 16.5 0 15.8 1.6 1.0 2.0 2.4 2.5
REF NO.
MODE 123456 123456
CD PLAY 12.0 12.0 16.1 17.8 12.0 12.0 5.0 5.0 16.2 17.8 5.0 5.0
STANDBY 12.0 12.0 16.1 17.8 12.0 12.0 5.0 5.0 16.2 17.8 5.0 5.0
Q2902 Q2903
SA-PT480PH POWER P.C.B.
IC2901
