Panasonic SA-PT480PH - Page 151

151
S6006 EVQ21405R SW VOL- 1
S6007 EVQ21405R SW SELECTOR 1
S6801 EVQ21405R SW POWER 1
S6807 EVQ21405R SW OPEN/CLOSE 1
1
CONNECTORS 1
CN1001 MFI514S0117 30P CONNECTOR 1
CN1002 K1MN15BA0139 15P CONNECTOR 1
CN2000 K1MN08A00068 8P CONNECTOR 1
CN2002 K1MN22AA0076 22P CONNECTOR 1
CN2003 K1MN10AA0076 10P CONNECTOR 1
CN2004 K1KA10A00430 10P CONNECTOR 1
CN2006 K1MN18A00061 18P CONNECTOR 1
CN2007 K1MN15AA0046 15P CONNECTOR 1
CN2916 K1KA03BA0116 3P CONNECTOR 1
CN2917 K1KA03BA0116 3P CONNECTOR 1
CN5400 K1KA06A00452 6P CONNECTOR 1
CN5401 K1KA03AA0301 3P CONNECTOR 1
CN5402 K1MN18AA0046 18P CONNECTOR 1
CN5802 K1KA03AA0292 3P CONNECTOR 1
CN5803 K1KA03AA0292 3P CONNECTOR 1
CN6001 K1YZ04000002 4P CABLE HOLDER 1
CN6401 K1KA05BA0061 5P CONNECTOR 1
CN6402 K1FY104B0011 USB CONNECTOR 1
CN7000 K1MN08B00013 8P CONNECTOR 1
FP8031 K1MY10AA0021 10P CONNECTOR 1
FP8251 K1MN07AA0076 7P CONNECTOR 1
FP8531 K1MN24A00062 24P CONNECTOR 1
FP9001 K1KA05AA0051 5P CONNECTOR 1
P3901 K1FY119E0014 HDMI CONNECTOR 1
P6001 K1MN22AA0004 22P CONNECTOR 1
1
COILS AND INDUC-
TORS
1
L1001 J0JFC0000006 INDUCTOR 1
L1002 J0JFC0000006 INDUCTOR 1
L1003 J0JGC0000071 INDUCTOR 1
L1004 J0JGC0000071 INDUCTOR 1
L1005 J0JGC0000071 INDUCTOR 1
L1006 J0JGC0000071 INDUCTOR 1
L1007 J0JGC0000071 INDUCTOR 1
L1008 J0JFC0000006 INDUCTOR 1
L1009 J0JFC0000006 INDUCTOR 1
L1010 J0JGC0000071 INDUCTOR 1
L1011 J0JFC0000006 INDUCTOR 1
L1032 J0JBC0000015 INDUCTOR 1
L2001 G1C4R7MA0172 INDUCTOR 1
L2510 G1C100K00019 INDUCTOR 1
L2700 J0JHC0000107 INDUCTOR 1
L2701 J0JHC0000107 INDUCTOR 1
L2703 J0JHC0000107 INDUCTOR 1
L2704 J0JHC0000107 INDUCTOR 1
L2705 J0JHC0000107 INDUCTOR 1
L2900 G1C100M00049 INDUCTOR 1
L2902 G0A200D00002 CHOKE COIL 1
L2903 G0A330ZA0045 CHOKE COIL 1
L2904 G0A330ZA0045 CHOKE COIL 1
L2907 J0JHC0000107 INDUCTOR 1
L2908 J0JHC0000107 INDUCTOR 1
L2951 G1CR18JA0020 INDUCTOR 1
L3903 G1BYYYC00026 COMMON MODE EMI
FILTER
1
L3904 G1BYYYC00026 COMMON MODE EMI
FILTER
1
L3905 G1BYYYC00026 COMMON MODE EMI
FILTER
1
L3906 G1BYYYC00026 COMMON MODE EMI
FILTER
1
L5100 G0C100M00006 INDUCTOR 1
L5101 G0C100M00006 INDUCTOR 1
L5103 G0B9R5K00005 LINE FILTER 1
L5104 G0B9R5K00005 LINE FILTER 1
L5105 G0B9R5K00005 LINE FILTER 1
L5106 G0B9R5K00005 LINE FILTER 1
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
L5200 G0C100M00006 INDUCTOR 1
L5201 G0C100M00006 INDUCTOR 1
L5203 G0B9R5K00005 LINE FILTER 1
L5204 G0B9R5K00005 LINE FILTER 1
L5300 J0JBC0000015 INDUCTOR 1
L5401 J0JKB0000003 INDUCTOR 1
L5402 J0JKB0000003 INDUCTOR 1
L5403 G1C4R7MA0172 INDUCTOR 1
L5702 ELF22V025A LINE FILTER 1
L5703 ELF22V025A LINE FILTER 1
L6006 J0JBC0000014 INDUCTOR 1
L6007 J0JBC0000014 INDUCTOR 1
L6100 J0JBC0000041 INDUCTOR 1
L6101 G0C390JA0055 INDUCTOR 1
L7001 J0JBC0000030 INDUCTOR 1
L7002 J0JBC0000030 INDUCTOR 1
L7004 J0JBC0000019 INDUCTOR 1
L7005 J0JBC0000019 INDUCTOR 1
L7006 J0JBC0000030 INDUCTOR 1
L7007 J0JBC0000019 INDUCTOR 1
L7008 J0JBC0000019 INDUCTOR 1
L8001 G1C100M00049 INDUCTOR 1
L8201 G1C100M00049 INDUCTOR 1
L8251 G1C100M00049 INDUCTOR 1
L8301 G1C100M00049 INDUCTOR 1
L8302 G1C100M00049 INDUCTOR 1
L8303 G1C100M00049 INDUCTOR 1
L8330 G1C100M00049 INDUCTOR 1
L8400 G1C100M00049 INDUCTOR 1
L8501 G1C100M00049 INDUCTOR 1
L8550 G1C100M00049 INDUCTOR 1
LB2031 J0JCC0000396 INDUCTOR 1
LB2032 J0JCC0000396 INDUCTOR 1
LB2033 J0JCC0000396 INDUCTOR 1
LB2039 J0JCC0000396 INDUCTOR 1
LB2068 J0JBC0000014 INDUCTOR 1
LB2091 J0JGC0000020 INDUCTOR 1
LB2092 J0JGC0000020 INDUCTOR 1
LB2151 J0JGC0000020 INDUCTOR 1
LB2152 J0JGC0000020 INDUCTOR 1
LB2153 J0JCC0000396 INDUCTOR 1
LB2300 J0JBC0000015 INDUCTOR 1
LB2301 J0JBC0000015 INDUCTOR 1
LB2302 J0JGC0000021 INDUCTOR 1
LB2400 J0JGC0000021 INDUCTOR 1
LB2616 J0JCC0000317 INDUCTOR 1
LB2750 J0JBC0000014 INDUCTOR 1
LB2751 J0JBC0000014 INDUCTOR 1
LB2752 J0JBC0000014 INDUCTOR 1
LB2753 J0JBC0000014 INDUCTOR 1
LB2754 J0JBC0000014 INDUCTOR 1
LB2755 J0JBC0000014 INDUCTOR 1
LB2756 J0JBC0000014 INDUCTOR 1
LB2757 J0JBC0000014 INDUCTOR 1
LB2758 J0JBC0000014 INDUCTOR 1
LB2759 J0JBC0000014 INDUCTOR 1
LB2760 J0JBC0000014 INDUCTOR 1
LB2761 J0JBC0000014 INDUCTOR 1
LB2763 J0JBC0000014 INDUCTOR 1
LB2764 J0JBC0000014 INDUCTOR 1
LB2765 J0JBC0000014 INDUCTOR 1
LB2766 J0JBC0000014 INDUCTOR 1
LB2767 J0JBC0000014 INDUCTOR 1
LB2768 J0JBC0000014 INDUCTOR 1
LB2769 J0JBC0000014 INDUCTOR 1
LB2770 J0JBC0000014 INDUCTOR 1
LB2771 J0JBC0000014 INDUCTOR 1
LB2772 J0JBC0000014 INDUCTOR 1
LB2773 J0JBC0000014 INDUCTOR 1
LB2774 J0JBC0000014 INDUCTOR 1
LB2777 J0JBC0000014 INDUCTOR 1
LB2800 J0JCC0000317 INDUCTOR 1
LB2801 J0JCC0000317 INDUCTOR 1
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
