Ref. No. Part No. Part Name & Description Remarks
TRAVERSE DECK
301 RML0517 TIMING LEVER [M]
302 RML0516 PLUNGER LEVER [M]
303 RMB0551 UPPER SPINDLE SPRING [M]
304 RMQ0744 LOWER HOOK [M]
305 RDV0056 BELT [M]
306 RML0525 FRONT LOCK [M]
307 RML0526 DISC LEVER [M]
308 RDG0424 DRIVE GEAR [M]
309 RDG0425 CHANGE GEAR [M]
310 RDG0427 TRV CAM GEAR [M]
311 RDG0428 TRV RELAY GEAR [M]
312 RDG0426 UP/DOWN GEAR [M]
313 RDG0429 PULLEY GEAR [M]
314 RMB0549-1 CHANGR GEAR SPRING [M]
315 RMQ0748 PITCH PLATE [M]
316 RMB0553 PUSH SPRING [M]
317 RML0530 ASSIST LEVER [M]
318 RML0518 CONNECTION LEVER [M]
319 RMM0201 SLIDE PLATE 1 [M]
320 RME0258 REAR LOCK SPRING [M]
321 RML0521 REAR LOCK LEVER [M]
322 RME0257 TRAY LOCK LEVER SPRING [M]
323 RML0520 TRAY LOCK [M]
324 RMM0202 SLIDE PLATE 2 [M]
325 XTB3+10J SCREW [M]
326 RMR1367-K FIXED PLATE [M]
327 RMR0624-W CLAMPER [M]
328 RMB0561 ASSIST LEVER SPRING [M]
329 RMR1121-K MECHA COVER [M]
330 RMA1110-2 TRAY ANGLE [M]
331 RMR1122-H1 TRAYBASE [M]
332 RMM0204 CARRIER [M]
333 RMM0203 DRIVE RACK [M]
334 RDG0432 SPEED UP GEAR [M]
335 RML0524 SLIDE LOCK [M]
336 RML0523 CARRIER LOCK [M]
337 RME0260-1 SLIDE LOCK SPRING [M]
338 RMR1123-H TRAY [M]
339 RXQ0595 MOTOR ASS’Y [M]
341 RSJ0003 SOLENOLD ASS’Y [M]
344 RML0519 8CD LEVER [M]
345 RFKNAAK27GCS MECHA BASE ASS’Y [M]
346 RML0522 TURNING STOPPER [M]
347 RMQ0745 LOWER SPINDLE [M]
348 RMQ0746 UP/DOWN BASE [M]
349 RMB0550 LOWER SPINDLE SPRING [M]
350 RMQ0747 UPPER HOOK [M]
351 RME0263 CLICK SPRING [M]
352 RMQ0743 SPINDLE SHAFT [M]
353 RMB0552 CUSHION SPRING [M]
354 RDG0430 RELAY GEAR A [M]
355 RDG0431 RELAY GEAR B [M]
356 RME0262 DISK LEVER SPRING [M]
357 RMA1105 SUPPORT PLATE [M]
369 RMX0141 PUSH SPACER [M]
370 RMQ0749 UPPER SPINDLE [M]
371 RHM0001 MAGNET [M]
372 RMX0140 DISC SPACER [M]
373 RME0261 FRONT LOCK SPRING [M]
374 RMQ0742 SPINDLE BASE [M]
375 RMA1435 PB ANGLE [M]
376 RMC0387 SUPPORT SPRING [M]
377 RMA1003 BACK YOKE [M]
378 XTV2+6G PCB SCREW [M]
379 XTW3+10T SCREW [M]
401 RMG0558-K P.C.B. RUBBER [M]
402 RHD20060 PCB SCREW [M]
403 RDG0499 TRAVERSE GEAR A [M]
404 RDG0500 TRAVERSE GEAR B [M]
405 RDG0501 TRAVERSE GEAR C [M]
Ref. No. Part No. Part Name & Description Remarks
406 RHD17044 DRIVE RACK SCREW [M]
407 RMC0415 ADJUST SPRING HOLDER [M]
409 RME0319 TRV GEAR SPRING [M]
413 RME0320 ADJUSTMENT SPRING [M]
414 RMM0234-1 TRV DRIVE RACK [M]
415 RMR1366-K1 UNIT CHASSIS [M]
416 RMG0545-A FLOATING RUBBER [M]
417 RMS0711 GUIDE SHAFT [M]
418 RMS0712-1 FIXED PIN [M]
420 RXQ0943 OPU UNIT [M]
421 VHD1224 ADJ SPRING HOLDER SCREW [M]
423 XQN17+C28 MOTOR SCREW [M]
424 RMS0710 DRIVE SHAFT [M]
425 RAF3023A-2S OPU UNIT [M]
426 RHD14095 FPC SCREW [M]
427 RJB2308A-1 INTERFACE FPC [M]
428 RMG0561-T CUSHION RUBBER [M]
429 RHD17029 SHAFT ADJUST SCREW [M]
430 RAE1825W-S TRAVERSE SUB UNIT [M]
24.2.2. CD Loading Mechanism Parts List
