Panasonic SA-VK61DEE - Page 145

Ref. No. Part No. Part Name & Description Remarks
CONNECTORS
CN1 K1MN14A00049 14P FFC CONNECTOR [M]
CN300 K1KB12B00036 12P CONNECTOR [M]
CN301 K1KB12B00036 12P CONNECTOR [M]
CN302 RJT029W03VT CONNECTOR [M]
CN303 K1MN26A00022 CONNECTOR [M]
CN304 RJS2A5615 15P FFC CONNECTOR [M]
CN305 K1KA02A00008 CONNECTOR [M]
CN306 K1MN17A00025 CONNECTOR [M]
CN307 K1KA11A00093 11P CONNECTOR [M]
CN309 RJS1A9414-1 14P CONNECTOR [M]
CN601 K1MN19A00026 19P FFC CONNECTOR [M]
CN602 K1MN30A00046 30P FFC CONNECTOR [M]
CN900 RJT066H08B 8P CONNECTOR [M]
CN900 K1KA02A00010 2P CONNECTOR [M]
CN950 RJT119W10V 10P CONNECTOR [M]
CN951 RJT119W07V 7P WIRE CONNECTOR [M]
CN953 RJT029W03VT CONNECTOR [M]
CN954 K1KA07A00058 7P CONNECTOR [M]
CN956 K1KB12B00036 12P CONNECTOR [M]
CN957 K1KB12B00036 12P CONNECTOR [M]
CN958 RJT119W15V 15P WIRE HOLDER [M]
CN971 K1MN10B00104 10P FFC CONNECTOR [M]
CN1001 K1MN14B00058 14P CONNECTOR [M]
CP100 K1KB11A00020 11P CONNECTOR [M]
CP500 K1KA12A00184 12P CONNECTOR [M]
CP501 K1KA12A00184 12P CONNECTOR [M]
CP502 K1KA12A00184 12P CONNECTOR [M]
CP503 K1KA12A00184 12P CONNECTOR [M]
CP600 K1MN10B00104 10P FFC CONNECTOR [M]
CP601 RJS1A9419-1 19P CONECTOR [M]
CP602 K1MN30A00046 30P FFC CONNECTOR [M]
CP603 RJS1A9414-1 14P CONNECTOR [M]
CP702 K1KB11A00020 11P CONNECTOR [M]
CP703 K1KA11A00093 11P CONNECTOR [M]
CP900 RJU066H08 8P CONNECTOR [M]
CS1001 RJS1A6805-J 5P CONNECTOR [M]
CS1002 RJS1A6805-J 5P CONNECTOR [M]
FP2501 K1MN04B00036 4P CONNECTOR [M]
FP3202 K1MN17B00041 17P CONNECTOR [M]
FP3203 K1MN15B00037 15P CONNECTOR [M]
FP4202 K1MN26B00037 26P CONNECTOR [M]
FP5101 K1MN30B00098 30P CONNECTOR [M]
FP5102 K1MN50B00010 50P CONNECTOR [M]
FP5201 K1MN50B00010 50P CONNECTOR [M]
COILS & TRANSFORMERS
L6 G0A101G00022 COIL [M]
L8 G0A100G00005 INDUCTOR [M]
L9 G0A101G00022 COIL [M]
L10 G0A100G00005 INDUCTOR [M]
L11 G0A100G00005 INDUCTOR [M]
L12 G0A100G00005 INDUCTOR [M]
L13 J0JBC0000019 CHIP INDUCTOR [M]
L50 ELESN220JA COIL [M]
L51 ELJFCR39KF CHIP INDUCTOR [M]
L52 VLP0145-T CHIP INDUCTOR [M]
L53 VLP0145-T CHIP INDUCTOR [M]
L54 VLP0145-T CHIP INDUCTOR [M]
L55 VLP0145-T CHIP INDUCTOR [M]
L56 VLP0145-T CHIP INDUCTOR [M]
L57 VLP0145-T CHIP INDUCTOR [M]
L58 J0JBC0000019 CHIP INDUCTOR [M]
L59 J0JBC0000019 CHIP INDUCTOR [M]
L60 J0JBC0000019 CHIP INDUCTOR [M]
L64 J0JBC0000041 CHIP INDUCTOR [M]
L65 J0JBC0000041 CHIP INDUCTOR [M]
L66 J0JBC0000041 CHIP INDUCTOR [M]
Ref. No. Part No. Part Name & Description Remarks
L67 J0JBC0000041 CHIP INDUCTOR [M]
L370 G0C221KA0007 COIL [M]
L500 RLQZ371 LINE FILTER [M]
L600 RLQB3R3KT-1Y COIL [M]
L601 G0C100JA0030 INDUCTOR [M]
L602 RLQZP101KT-Y AXIAL COIL [M]
L603 RLQZP101KT-Y AXIAL COIL [M]
L604 RLQZP100KT-Y AXIAL COIL [M]
L605 RLQZP100KT-Y AXIAL COIL [M]
L607 G0C3R3JA0030 COIL [M]
L608 G0C100JA0030 INDUCTOR [M]
L609 RLQZP100KT-Y AXIAL COIL [M]
L610 G0C470JA0030 RF CHOKE COIL [M]
L700 G0C100JA0030 INDUCTOR [M]
L981 RLQZR73MT-T CHOKE COIL [M]
L991 RLQZR73MT-T CHOKE COIL [M]
L1001 G0C470JA0030 RF CHOKE COIL [M]
L1002 7L1A62N BIAS OSC COIL [M]
L2001 G1C100K00020 CHIP INDUCTOR [M]
L2002 G1C100K00020 CHIP INDUCTOR [M]
L3101 G1C100K00020 CHIP INDUCTOR [M]
L4211 G1C220KA0038 CHIP CAPACITOR [M]
L5101 ELJEA100KF CHIP INDUCTOR [M]
L5221 G1C100K00020 CHIP INDUCTOR [M]
L6561 G1C220KA0038 CHIP CAPACITOR [M]
L6562 G1C220KA0038 CHIP CAPACITOR [M]
T501 G4C8AGC00001 MAIN TRANSFORMER [M]
T502 G4C2AAJ00005 BACK-UP TRANSFORMER [M]
COMPONENT COMBINATION
Z101 RLA2Z007-T COIL [M]
Z102 G2BAE0000003 AM IF BLOCK [M]
Z120 ENV17290G1Y FM TUNER PACK [M]
Z501 ERZV10V511CS ZENER [M]
Z600 B3RAB0000025 REMOTE SENSOR [M]
Z971 RGSD12A1445T RADA RESISTOR [M]
BS4 RMBX0031 GROUNDING SPRING [M]
CERAMIC FILTERS
CF201 RLFFETNGD01L CERAMIC FILTER [M]
CF202 RLFFETMGD01L CERAMIC FILTER [M]
RELAY
RL502 RSY0040M-0 PRIMARY RELAY [M]
OSCILLATORS
X102 RLFDFT22DD DISCRIMINATOR [M]
X103 RSXC7M20S05T CRYSTAL OSCILLATOR [M]
X601 H2A100500006 RESONATOR [M]
X602 H0A327200073 CRYSTAL OSCILLATOR [M]
X700 H0H368600001 CRYSTAL OSCILLATOR [M]
X6501 H0J368600003 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL600 A2BD00000071 FL DISPLAY [M]
FL4201 F1H0J1050018 1 6.3V [M]
FL6251 F1J1E1040022 0.1 25V [M]
FL6252 F1H0J1050018 1 6.3V [M]
FL6253 F1H0J1050018 1 6.3V [M]
FL6254 F1H0J1050018 1 6.3V [M]
FUSES
F1 K5D162BK0005 1.6A FUSE [M]
F3 K5D632BK0007 6.3A FUSE [M]
F4 K5D632BK0007 6.3A FUSE [M]
145
SA-VK61DEE
