Panasonic TH-42PV70H

Receiving Channels VHF BAND
(Regular TV) 2-12 (PAL/SECAM B, K1) 0-12 (PAL B AUST.)
1-9 (PAL B N.Z.) 1-12 (PAL/SECAM D)
1-12 (NTSC M Japan) 2-13 (NTSC M USA)
UHF BAND
21-69 (PAL G, H, I/SECAM G, K, K1) 28-69 (PAL B AUST.)
13-57 (PAL D, K) 13-62 (NTSC M Japan)
14-69 (NTSC M USA)
CATV
S1-S20 (OSCAR) 1-125 (USA CATV)
C13-C49 (JAPAN) S21-S41 (HYPER)
Z1-Z37 (CHINA) 5A, 9A (AUST.)
Aerial - Rear VHF / UHF
Operating Conditions Temperature: 0 °C - 40 °C
Humidity: 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 Input
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 ohm)
S VIDEO Mini DIN 4-pin Y:1.0 V[p-p] (75 ohm) C:0.286 V[p-p] (75 ohm)
AV2 Input
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 ohm)
COMPONENT Y 1.0 V [p-p] (including synchronization)
P
B
/C
B,
P
R
/C
R
± 0.35 V [p-p]
AV3 Input
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 ohm)
COMPONENT Y 1.0 V [p-p] (including synchronization)
P
B
/C
B,
P
R
/C
R
± 0.35 V [p-p]
AV4 Input
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 ohm)
S VIDEO Mini DIN 4-pin Y:1.0 V[p-p] (75 ohm) C:0.286 V[p-p] (75 ohm)
Others
HDMI1 / 2 Input TYPE A Connectors
· This TV supports “HDAVI Control 2” function.
PC Input HIGH-DENSITY D-SUB 15PIN R,G,B/0.7 V [p-p] (75 ohm)
HD, VD/TTL Level 2.0 - 5.0 V [p-p] (high impedance)
Audio Input RCA PIN Type × 2 0.5 V[rms]
Monitor Output
AUDIO L-R RCA PIN Type × 2 0.5 V [rms] (high impedance)
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 ohm)
Dimensions (W × H × D) 1,020 mm × 750 mm × 320 mm (With Pedestal)
1,020 mm × 705 mm × 94 mm (TV only)
Mass 30.0 k Net (With Pedestal)
28.0 k Net (TV only)
Note:
· Design and Specifications are subject to change without notice. Weight and Dimensions shown are approximate.
2
TH-42PV70AZ / TH-42PV70H / TH-42PV70M / TH-42PV70MR / TH-42PV70MT
