Panasonic TH-50PC77U - 16.4. Mechanical Replacement Parts List (PDP TV)

Note:
All parts except parts mentioned [PAVCA] in the Remarks
column are supplied by PAVC-CSG.
Parts mentioned [PAVCA] are supplied by PAVCA.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
1 10030-0035400 BATTERY COVER 1 PAVCA
2 EAS12S10B SPEAKER 2
3 K1RGZBA00001 F TERMINAL (5C
TYPE)
1
4 K2CG3DH00025 AC CORD 1
5 MD50H10A1J PLASMA DISPLAY
PANEL
1
6 N2QAYB000100 REMOTE CONTROL 1 PAVCA
7 TBMA231 PANASONIC BADGE 1 TH-50PE77U
PAVCA
8 TBX2AA4402 POWER BUTTON 1 PAVCA
9 TBX2AA4501 CONTROL BUTTON 1 PAVCA
10 TESD078 BUTTON SPRING 1
THEL0429 SCREW 18
THEL047J SCREW (HDMI:2) 2
THTA0419 HOOK SCREW 2
THTD011J SCREW 3
THTF011N SCREW 99
11 TKGA5345S FRONT GLASS 1 TH-50PX77U
PAVCA
11 TKGA5325S FRONT GLASS 1 TH-50PE77U
PAVCA
12 TKK2AA7701 ADJUSTMENT COVER 1 PAVCA
13 TKK2AA8001 PANEL LIGHT 1 PAVCA
14 TKP2AA1912 INLET COVER 1 PAVCA
15 TKP2AA1932 M8 SPACER CAP 4 PAVCA
16 TKR2AA00161 REAR COVER
HANDLE
2 PAVCA
17 TKR2AA00191 IR FILTER CAP 1 PAVCA
TMM14490 CLAMPER 2
TMM16473-1 CLAMPER 4
18 TMM2AE0541 M8 SPACER 4 PAVCA
TMM6428-1 CLAMPER 2
TMM7468-1 CLAMPER 1
TMM81416 CORD BAND
(SMALL)
1
TMME061 CLAMPER 3
TMME084 CLAMPER 1
TMME226 AC CORD CLAMPER 1
TMME260 CLAMPER 16
TMME285 CLAMPER 1
TMME287 CLAMPER 1
30 TMME289 CLAMPER 2
19 TMZ2AK1001 SPEAKER HOLDER A 1 PAVCA
20 TMZ2AK1002 SPEAKER HOLDER B 1 PAVCA
21 TMZ2AX0211 STAND BRACKET
(LEFT)
1 PAVCA
22 TMZ2AX0221 STAND BRACKET
(RIGHT)
1 PAVCA
TPD169487 JOINT 4
23 TQB2AA0753 INSTRUCTION
BOOK(ENG/FRE/SPA
)
1 TH-50PX77U
PAVCA
23 TQB2AA0756 INSTRUCTION
BOOK(ENG/FRE/SPA
)
1 TH-50PE77U
PAVCA
TSXL519 CABLE (C10-C20) 1
TSXL554 CABLE (C22-C32) 1
TSXL604 CABLE (SC20-D20) 1
24 TXAJS01RSER INLET ASSY 1 PAVCA
25 TXFKP07RSER SIDE AV BRACKET 1 PAVCA
26 TXFKP08RSER SIDE AV DOOR
ASSY
1 PAVCA
27 TXFKP09RSER SIDE AV HOLDER
ASSY
1 PAVCA
28 TXFKU08RSER REAR COVER 1 PAVCA
29 TXFKY01LGTU CABINET ASSY 1 TH-50PX77U
PAVCA
Ref. No. Part No. Part Name &
Description
Pcs Remarks
29 TXFKY01LJTU CABINET ASSY 1 TH-50PE77U
PAVCA
TXJA12LGTU SPEAKER LEAD
(A12-SPL/SPR)
1 PAVCA
TXJSWRLHTU SPEAKER LEAD
(L/R)
1 PAVCA
XTB4+12GFJ SCREW 42
XTB4+12GFJK SCREW 28
XTV3+10JFJK SCREW 1
XTV3+8GFJK SCREW 7
XYN3+F10FJ SCREW 1
XYN3+F8FJ SCREW 27
XYN3+J12FJ SCREW 42
XYN3+J6FJ SCREW 1
XYN4+E8FJ SCREW 1
XYN4+F10FJ SCREW 16
XYN4+F10FJK SCREW 13
XYN5+C15FJ SCREW 8
16.4. Mechanical Replacement Parts List (PDP TV)
110
TH-50PX77U / TH-50PE77U
