Note:
All parts except parts mentioned [PAVCA] in the Remarks
column are supplied by PAVC-CSG.
Parts mentioned [PAVCA] are supplied by PAVCA.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
F601.602 K5D103BMA001 TIME LAG FUSE
HIGH
2
A1 K1KA07A00271 7P CONNECTOR 1
A5 K1KB31AA0140 31P CONNECTOR 1
A6 K1KA12AA0191 12P CONNECTOR 1
A7 K1KA11AA0191 11P CONNECTOR 1
A12 K1KA04AA0192 4P CONNECTOR 1
A17 K1KA14A00248 14P CONNECTOR 1
A18 K1KA11AA0153 11P CONNECTOR 1
A51 K1KA11AA0194 11P CONNECTOR 1
A52 K1KA13A00152 13P CONNECTOR 1
C10 K1MN20BA0231 20P CONNECTOR 1
C11 K1MN55BA0076 55P CONNECTOR 1
C20 K1MN20BA0231 20P CONNECTOR 1
C21,22 K1MN68BA0076 68P CONNECTOR 2
C32 K1MN68BA0076 68P CONNECTOR 1
C33 K1KA10B00218 10P CONNECTOR 1
C35 K1KA04BA0107 4P CONNECTOR 1
C251 MBB224K2 CERAMIC CHIP
CAPACITOR
1
C354 MBB224K2 CERAMIC CHIP
CAPACITOR
1
C1102 F1J0J1060004 C 0.010UF, K,
16V
1
C1103,04 F1G1A104A012 C 0.1UF, K, 10V 2
C1105 F1H0J1050012 C 1UF, K, 16V 1
C1106 F1H1H2700008 E 27UF, 50V 1
C1107 F1H1H2200008 E 22UF, 50V 1
C1108 F1G1A104A012 C 0.1UF, K, 10V 1
C1109 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C1111 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C1112 F1G1A104A012 C 0.1UF, K, 10V 1
C1114 F1G1A104A012 C 0.1UF, K, 10V 1
C1117 F1G1A104A012 C 0.1UF, K, 10V 1
C1122 ECJ0EB1C103K C 0.010UF, K,
16V
1
C1123 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C1193,94 F1J0J1060004 C 0.010UF, K,
16V
2
C1197 F1G1H101A565 C 100PF, K, 50V 1
C2023 F1G1C104A081 C 0.10UF, K, 16V 1
C2048-50 F1G1C104A081 C 0.10UF, K, 16V 3
C2052,53 F1G1C104A081 C 0.10UF, K, 16V 2
C2054 F1J1A106A043 C 0.010UF, K,
16V
1
C2055,56 ECJ0EC1H120J C 120PF, K, 50V 2
C2057,58 F1G1C104A081 C 0.10UF, K, 16V 2
C2059 F2G0J470A019 E 47UF 6.3V 1
C2100 F1G1C104A081 C 0.10UF, K, 16V 1
C2101 F1J1A106A043 C 0.010UF, K,
16V
1
C2102 F1G1C104A081 C 0.10UF, K, 16V 1
C2103 EEEHB1C101UP C 100PF, J, 16V 1
C2105,06 F1G1C104A081 C 0.10UF, K, 16V 2
C2107,08 F2G0J470A019 E 47UF 6.3V 2
C2111 F1H0J2250008 C 2.2UF, K, 16V 1
C2116 F1H1H471A792 E 470UF, 50V 1
C2118 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C2126 F1J1A106A043 C 0.010UF, K,
16V
1
C2133 F2G0J470A019 E 47UF 6.3V 1
C2134 ECJ0EB1C103K C 0.010UF, K,
16V
1
C2143 F1H1H181A792 E 180UF, 50V 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
C2146 F1H1H181A792 E 180UF, 50V 1
C2153 ECJ1VC1H330J C 33PF, J, 50V 1
C2170 ECJ1VC1H330J C 33PF, J, 50V 1
C2171 ECJ0EB1C103K C 0.010UF, K,
16V
1
C2173 ECJ2FF1C475Z C 0.047UF, Z,
16V
1
C2183 F1J1A106A043 C 0.010UF, K,
16V
1
C2185 F1J1A106A043 C 0.010UF, K,
16V
1
C2186 F1G1C104A081 C 0.10UF, K, 16V 1
C2187 F1H0J2250008 C2.2UF,K,16V 1
C2188 F1H1H471A792 E 470UF, 50V 1
C2189 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C2190,91 F1J1A106A043 C 0.010UF, K,
16V
2
C2192 F2G0J470A019 E47UF6.3V 1
C2213 ECJ1VB1H102K C 1000UF, Z, 50V 1
C2216 F1G1C104A081 C 0.10UF, K, 16V 1
C2244 F1G1C104A081 C 0.10UF, K, 16V 1
C2245 ECJ1VB1H102K C 1000UF, Z, 50V 1
C2246 F1J1A106A043 C 0.010UF, K,
16V
1
C2251 F1J1A106A043 C 0.010UF, K,
16V
1
C2263,64 ECJ2FB1A475K C4.7UF,K,10V 2
C2267,68 ECJ1XC1H101J C100PF,J,50V 2
C2274 F1G1C104A081 C 0.10UF, K, 16V 1
C2301,02 F1G1C104A081 C 0.10UF, K, 16V 2
C2303 F1J1E105A171 E 1 UF 25V 1
C2305 F1J1E105A171 E 1 UF 25V 1
C2307 F1J1E105A171 E 1 UF 25V 1
C2309 F1J1E105A171 E 1 UF 25V 1
C2313 ECJ1XB1H104K C 10PF, J, 50V 1
C2317 ECJ1VB1C333K C 0.033UF, K,
16V
1
C2319 ECJ1VB1C333K C 0.033UF, K,
16V
1
C2321 ECJ1VB1C333K C 0.033UF, K,
16V
1
C2323 ECJ1VB1C333K C 0.033UF, K,
16V
1
C2325 F1J1H474A757 C 0.47UF, 50V 1
C2331 F1J1H474A757 C 0.47UF, 50V 1
C2333 ECJ1XB1H104K C 10PF, J, 50V 1
C2335 ECJ1XB1H104K C 10PF, J, 50V 1
C2337 F1H1H223A219 E 0.022UF, 50V 1
C2339 F1H1H223A219 E 0.022UF, 50V 1
C2341 ECJ1XB1H104K C 10PF, J, 50V 1
C2343 ECJ1XB1H104K C 10PF, J, 50V 1
C2345 F1H1H223A219 E 0.022UF, 50V 1
C2347 F1H1H223A219 E 0.022UF, 50V 1
C2349 F1G1C104A081 C 0.10UF, K, 16V 1
C2352 ECJ1VB1C105K C 0.01UF, K, 16V 1
C2353 ECJ1XB1H104K C 10PF, J, 50V 1
C2355 ECJ1XB1H104K C 10PF, J, 50V 1
C2357 ECJ1XB1H104K C 10PF, J, 50V 1
C2359 ECJ1XB1H104K C 10PF, J, 50V 1
C2361 EEEFG1E471P E 470UF, 25V 1
C2363 EEEHB1C221UP C220PF,J,16V 1
C2365 F1G1C104A081 C 0.10UF, K, 16V 1
C2367 F1G1C104A081 C 0.10UF, K, 16V 1
C2369 F1G1C104A081 C 0.10UF, K, 16V 1
C2371 F1G1C104A081 C 0.10UF, K, 16V 1
C2373 F1G1C104A081 C 0.10UF, K, 16V 1
C2375 F1H1H223A219 E 0.022UF, 50V 1
C2377 F1H1H223A219 E 0.022UF, 50V 1
C2379 F1H1H223A219 E 0.022UF, 50V 1
C2381 F1H1H223A219 E 0.022UF, 50V 1
C2383 ECJ1VB1H102K C 1000UF, Z, 50V 1
C2385 ECJ1VB1H102K C 1000UF, Z, 50V 1
C2387 ECJ1VB1H102K C 1000UF, Z, 50V 1
16.6. Electrical Replacement Parts List
112
TH-50PX77U / TH-50PE77U
