Panasonic TH-50PC77U - Page 93

Ref. No. Part No. Part Name &
Description
Pcs Remarks
C2389 ECJ1VB1H102K C 1000UF, Z, 50V 1
C2512 ECJ3XB0J106M C 10UF, M,6.3V 1
C2515 ECJ1VB1H103K C 0.001UF, K,
50V
1
C2521 ECJ1VB1H103K C 0.001UF, K,
50V
1
C3001 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3003 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3005 ECJ0EB1C103K C 0.010UF, K,
16V
1
C3006 F1G1C104A081 C 0.10UF, K, 16V 1
C3007 F2G1A101A019 E 100UF, 10V 1
C3014 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3016 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3018 ECJ0EB1C103K C 0.010UF, K,
16V
1
C3020 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3025 F1G1C104A081 C 0.10UF, K, 16V 1
C3032 EEEHB1C220R C 22PF, J, 16V 1
C3033 EEEHB1A221P C 220PF, J, 10V 1
C3045 F1G1C104A081 C 0.10UF, K, 16V 1
C3069 F1G1C104A081 C 0.10UF, K, 16V 1
C3071 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3073 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3075 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3077 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3079 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3081 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3086 EEEHB1C100R C 10PF, J, 16V 1
C3087 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3095 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3097 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3099 ECJ0EB1C103K C 0.010UF, K,
16V
1
C3103,04 ECJ1VB1A105K C 0.01UF, Z, 50V 2
C3105 F1G1C104A081 C 0.10UF, K, 16V 1
C3106-17 ECJ1VB1A105K C 0.01UF, Z, 50V 12
C3120,21 ECJ1VB1A105K C 0.01UF, Z, 50V 2
C3123,24 F1K1A106A021 C 0.010UF,
K,6.3V
2 PAVCA
C3132,33 F1H0J2250008 C 2.2UF, K, 16V 2
C3138 EEEHB1C220R C 22PF, J, 16V 1
C3145 F2G1A101A019 E 100UF, 10V 1
C3146 F1G1C104A081 C 0.10UF, K, 16V 1
C3153 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C3157 F1G1C104A081 C 0.10UF, K, 16V 1
C3502 F2A1C471A537 E 470UF, 16V 1
C3503 F1G1C104A081 C 0.10UF, K, 16V 1
C3504 F2A1C471A537 E 470UF, 16V 1
C3505 F1G1C104A081 C 0.10UF, K, 16V 1
C3513,14 F1G1C104A081 C 0.10UF, K, 16V 2
C3515 F2A1H331A257 E 330UF, 50V 1
C3516 ECJ1VB1E104K C 0.10UF, K, 25V 1
C3530 EEEFG1E471P E 470UF, 25V 1
C3750 F1J1H102A721 E 1000UF, 50V 1
C4075 F1G1C104A081 C 0.10UF, K, 16V 1
C4077,78 ECJ1VB1C105K C 0.01UF, K, 16V 2
C4500-03 F1G1C104A081 C 0.10UF, K, 16V 4
C4506,07 F1G1C104A081 C 0.10UF, K, 16V 2
C4508,09 EEEHB0J330R C 33PF, J, 6.3V 2
C4510,11 F1G1C104A081 C 0.10UF, K, 16V 2
C4515 F1G1C104A081 C 0.10UF, K, 16V 1
C4527 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4528 F1G1C104A081 C 0.10UF, K, 16V 1
C4531 F1G1C104A081 C 0.10UF, K, 16V 1
C4533 F1G1H680A565 E 68UF, 50V 1
C4534,35 F1G1C104A081 C 0.10UF, K, 16V 2
C4538 F2G0J470A019 E 47UF 6.3V 1
C4539 F1J1A106A043 C 0.010UF, K,
16V
1
C4541 F1H1H471A219 E 470UF, 50V 1
C4543-45 F1G1C104A081 C 0.10UF, K, 16V 3
C4546 F1H0J2250008 C 2.2UF, K, 16V 1
C4547 F1G1C104A081 C 0.10UF, K, 16V 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
C4548,49 ECJ1XB1H104K C 10PF, J, 50V 2
C4550,51 F1G1C104A081 C 0.10UF, K, 16V 2
C4552 ECJ1XB1H104K C 10PF, J, 50V 1
C4553 F1G1H1020008 E 1000UF, 50V 1
C4555,56 F1J1A106A043 C 0.010UF, K,
16V
2
C4557 F1G1C104A081 C 0.10UF, K, 16V 1
C4559,60 F1G1C104A081 C 0.10UF, K, 16V 2
C4562 F1H1H822A219 E 8200UF, 50V 1
C4563 ECJ1VB1C823K C 0.082UF, K,
16V
1
C4564,65 F1G1E1030005 C 0.01UF, Z, 25V 2
C4566 ECJ1XB1C393K C 0.039UF, K,
16V
1
C4568 F1G1C104A081 C 0.10UF, K, 16V 1
C4569 F1J1C684A097 C 0.68UF, Z, 16V 1
C4570 F2G0J470A019 E47UF6.3V 1
C4572,73 F1G1C104A081 C 0.10UF, K, 16V 2
C4574 F1G1E1030005 C 0.01UF, Z, 25V 1
C4575 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4576 EEEHB1C220R C 22PF, J, 16V 1
C4577,78 F1G1C104A081 C 0.10UF, K, 16V 2
C4580 F1G1E1030005 C 0.01UF, Z, 25V 1
C4581 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4582,83 F1G1C104A081 C 0.10UF, K, 16V 2
C4584,85 ECJ1VB1A105K C 0.01UF, Z, 50V 2
C4586 F1G1E1030005 C 0.01UF, Z, 25V 1
C4587 F1G1C104A081 C 0.10UF, K, 16V 1
C4588 ECJ1VB1C823K C 0.082UF, K,
16V
1
C4589 F1G1H150A565 E 15UF, 50V 1
C4590 F1G1H180A565 E 18UF, 50V 1
C4593 F1G1E1030005 C 0.01UF, Z, 25V 1
C4595 F1G1E1030005 C 0.01UF, Z, 25V 1
C4596 F1G1C104A081 C 0.10UF, K, 16V 1
C4598 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4600,01 F1G1E1030005 C 0.01UF, Z, 25V 2
C4602 F1G1C104A081 C 0.10UF, K, 16V 1
C4604 F1H0J2250008 C 2.2UF, K, 16V 1
C4605 F1G1C104A081 C 0.10UF, K, 16V 1
C4607 F2G0J470A019 E47UF6.3V 1
C4609 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4611 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4612 F1G1E1030005 C 0.01UF, Z, 25V 1
C4613 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4614 F1G1C104A081 C 0.10UF, K, 16V 1
C4615 F1G1E1030005 C 0.01UF, Z, 25V 1
C4616,17 F1G1C104A081 C 0.10UF, K, 16V 2
C4618 F1G1E1030005 C 0.01UF, Z, 25V 1
C4619 F1G1C104A081 C 0.10UF, K, 16V 1
C4620 ECJ1VB1A105K C 0.01UF, Z, 50V 1
C4623-25 F1G1C104A081 C 0.10UF, K, 16V 3
C4630 F1G1C104A081 C 0.10UF, K, 16V 1
C4701 F1G1H1020008 E 1000UF, 50V 1
C4702 F1G1A104A012 C 0.1UF, K, 10V 1
C4703 F1G1H1020008 E 1000UF, 50V 1
C4704,05 F1G1A104A012 C 0.1UF, K, 10V 2
C4711,12 F1G1A104A012 C 0.1UF, K, 10V 2
C4713,14 F1G1H1020008 E 1000UF, 50V 2
C4715 F1G1A104A012 C 0.1UF, K, 10V 1
C4716-19 F1G1H1020008 E 1000UF, 50V 4
C4721 F1G1A104A012 C 0.1UF, K, 10V 1
C4722-24 F1G1H1020008 E 1000UF, 50V 3
C4741 F1G1H1020008 E 1000UF, 50V 1
C4742 F1G1A104A012 C 0.1UF, K, 10V 1
C4743 F1G1H1020008 E 1000UF, 50V 1
C4744,45 F1G1A104A012 C 0.1UF, K, 10V 2
C4746 F1G1H1020008 E 1000UF, 50V 1
C4751-55 F1G1A104A012 C 0.1UF, K, 10V 5
C4761-63 ECJ1VB1H103K C 0.001UF, K,
50V
3
C4771 F1G1H1020008 E 1000UF, 50V 1
C4772 F1G1A104A012 C 0.1UF, K, 10V 1
C4773 F1G1H1020008 E 1000UF, 50V 1
