Panasonic TH-50PHW7BX - 18 Mechanical Replacement Parts List

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
1 EUR646529 REMOTE CONTROL 1 TH-
50PHD7BK/BS/E
K/ES/UY
1 EUR646530 REMOTE CONTROL 1 TH-
50PHW7BX/EX
J0KD00000071 FLAT CORE 4
2 J0KF00000018 FILTER 1
3 J0KG00000054 NOISE FILTER 2
K1LB03A00056 FAN 1
K2AH3H000027 AC INLET 1
4 K2CG3DH00025 AC CORD 1 TH-50PHD7UY
4 K2CT3DH00018 AC CORD 1 TH-
50PHD7BK/BS,T
H-50PHW7BX
4 K2CN3DH00006 AC CORD 1 TH-
50PHD7EK/ES,T
H-50PHW7EX
K4DQD000041 CABLE TERMINAL 40
L6FALEFH0028 FAN 1
5 MD50H07A1J PLASMA DISPLAY
PANEL
1
TBMA008 PANASONIC BADGE 1 TH-
50PHD7BK/EK/U
Y
TBMA118 PANASONIC BADGE 1 TH-
50PHD7BS/ES,T
H-50PHW7BX/EX
6 TBXA28202A POWER BUTTON 1 TH-
50PHD7BK/EK/U
Y
6 TBXA28214 POWER BUTTON 1 TH-
50PHD7BS/ES,T
H-50PHW7BX/EX
7 TBXA38902 HINDGE BUTTON 1 TH-
50PHD7BK/EK/U
Y
7 TBXA38901 HINDGE BUTTON 1 TH-
50PHD7BS/ES,T
H-50PHW7BX/EX
8 TESD031 SPRING 1
THEA068N SCREW 4
THEL023Z SCREW 18
THEL027N SCREW 29
THEL035N SCREW 137
THTD010N SCREW 3
THTD011 SCREW 3
9 TKGA5175 FRONT GLASS 1 TH-
50PHD7BK/BS/E
K/ES/UY
9 TKGA5176 FRONT GLASS 1 TH-
50PHW7BX/EX
10 TKKC5105 LED PANEL 1
TKKL5266 COVER 1
11 TKPA60301 REMOCON RECEIVE
PANEL
1 TH-
50PHD7BK/EK/U
Y
11 TKPA60302 REMOCON RECEIVE
PANEL
1 TH-
50PHD7BS/ES,T
H-50PHW7BX/EX
12 TKPA63401 PHOTO IC RECEIVE
PANEL
1
13 TKRA20501 HANDLE 2
TMKG252 CUSHION 2
TMKG253 CUSHION 2
TMKG335 CUSHION (FAN
CENTER)
1
TMKG358 CUSHION 1
TMKG359 CUSHION 1
TMM15414-2 CLAMPER 1
TMM17499 CLAMPER 1
TMM23416 SPACER 12
TMM25401 CLAMPER 7
TMM7464-2 CLAMPER 1
TMM7468-1 CLAMPER 3
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
TMME047 CLAMPER 4
TMME061 CLAMPER 2
TMME061 CLAMPER 2
TMME075 EADG SADOLE 1
TMME152 CLAMPER 1
TMME185 CLAMPER 2
TMME187 CLAMPER 2
TMME189 CLAMPER 1
TMME189 CLAMPER 1
TMME190 CLAMPER 1
TMME199 CLAMPER 5
TMME225 AC CORD CLAMPER 1
TMME228 CLAMPER 2
TMMJ074 CUSHION (RUBBER) 3
TMMJ082 CUSHION (RUBBER) 4
TMMX079 CLAMPER 4
TMMX095 BRACKET 2
TMWC006-1 POWER BUTTOM
BRACKET
1
14 TPCA97201A CARTON BOX(BOTTOM) 1
15 TPCB45602 CARTON BOX 1 TH-50PHD7UY
15 TPCB51817 CARTON BOX 1 TH-50PHW7BX
15 TPCB51816 CARTON BOX 1 TH-50PHW7EX
15 TPCB51818 CARTON BOX 1 TH-50PHD7ES
15 TPCB51812 CARTON BOX 1 TH-50PHD7EK
15 TPCB51813 CARTON BOX 1 TH-50PHD7BK
15 TPCB51819 CARTON BOX 1 TH-
50PHD7BS/ES,T
H-50PHW7BX/EX
16 TPD169487 JOINT 8 TH-50PHD7UY
16 TPD169487 JOINT 4 TH-
50PHD7BK/BS/E
K/ES,TH-
50PHW7BX/EX
17 TPDA0675 CUSHION(UPPER ) 1 TH-50PHD7UY
18 TPDA0676 CUSHION(CENTER) 1 TH-50PHD7UY
19 TPDA0794 CUSHION(BOTTOM) 1 TH-50PHD7UY
20 TPDA0943 CUSHION(UPPER) 1
21 TPDA0944 CUSHION(BOTTOM) 1
22 TPDF0536 PAD(TOP) 1
23 TPDF0737 PAPER BOX 1
24 TPDF0906 PAD(TOP) 1 TH-50PHD7UY
25 TPEH170 PROTECT COVER 1
26 TPGA2170 CARTON BOX(BOTTOM) 1 TH-50PHD7UY
27 TQBC0835 INSTRUCTION
BOOK(FRENCH)
1 TH-50PHD7UY
27 TQBC0840 INSTRUCTION
BOOK(ENGLISH)
1 TH-50PHD7UY
27 TQBC0841 INSTRUCTION
BOOK(SPANISH)
1 TH-50PHD7UY
27 TQBC0906 INSTRUCTION
BOOK(ENGLISH)
1 TH-50PHW7BX
27 TQBC0898 INSTRUCTION
BOOK(ENGLISH)
1 TH-50PHW7EX
27 TQBC0899 INSTRUCTION
BOOK(GERMAN)
1 TH-50PHW7EX
27 TQBC0900 INSTRUCTION
BOOK(FRENCH)
1 TH-50PHW7EX
27 TQBC0901 INSTRUCTION
BOOK(ITALIAN)
1 TH-50PHW7EX
27 TQBC0902 INSTRUCTION
BOOK(SPANISH)
1 TH-50PHW7EX
27 TQBC0903 INSTRUCTION
BOOK(DUTCH)
1 TH-50PHW7EX
27 TQBC0904 INSTRUCTION
BOOK(DANISH)
1 TH-50PHW7EX
27 TQBC0905 INSTRUCTION
BOOK(SWEDISH)
1 TH-50PHW7EX
18 Mechanical Replacement Parts List
127
TH-50PHW7BX / TH-50PHW7EX / TH-50PHD7EK / TH-50PHD7ES / TH-50PHD7BK / TH-50PHD7BS / TH-50PHD7UY
