Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
D532 MA3J142D0L DIODE 1
D534 MA752A DIODE 1
D535 MA188 DIODE 1
D536 MA752A DIODE 1
D537 B0HBRP000007 DIODE 1
D538 MA4051NM ZENER DIODE 1
D539 B0HBRP000007 DIODE 1
D543-45 MA4200H ZENER DIODE 3
D547 MA4150M ZENER DIODE 1
D548 MA4075M ZENER DIODE 1
D549 MA188 DIODE 1
D551 MA4075M ZENER DIODE 1
D554 ERA15-01V5 DIODE 1
D555 MA4075M ZENER DIODE 1
D557 MA111 DIODE 1
D559 MA4075M ZENER DIODE 1
D561 MA4075M ZENER DIODE 1
D563,64 MA111 DIODE 2
D572 MA188 DIODE 1
F405 P130A FUSE 1
IC401 CNC1S171R IC 1
IC402 C0BBAA000038 IC 1
IC403,0
4
CNC1S171R IC 2
IC405 C0CBADE00037 IC 1
IC406 C0DAZZZ00021 IC 1
IC408 CNC1S171R IC 1
IC409 MIP2C20MPSAG IC 1
IC410 C0CBADE00037 IC 1
IC411 C0BBAA000038 IC 1
IC501 C2ABFD000148 IC 1
IC502 C0EBE0000154 IC 1
IC503 C0ZBZ0000383 IC 1
IC504 C0DAEMB00003 IC 1
IC507 C0CBABE00041 IC 1
IC512 C0DAEMB00003 IC 1
IC520 C0JBAZ002056 IC 1
IC521 C0JBAF000540 IC 1
IC522 C0JBAZ002056 IC 1
IC523 C0JBAF000540 IC 1
IC524,2
5
C0BBAA000039 IC 2
L402 EXCELSA24 BEAD CHOKE 1
L403 EXCELSA35 BEAD CHOKE 1
L505 EXCELDR35C BEAD CHOKE 1
L506,07 EXCELDR25C BEAD CHOKE 2
P2 K1KA06A00180 6P CONNECTOR 1
P5 K1KA11A00073 11P CONNECTOR 1
P7 K1KA04A00242 4P CONNECTOR 1
P9 K1KA03A00181 3P CONNECTOR 1
P10 K1KA05A00177 5P CONNECTOR 1
P11 K1KA07A00096 7P CONNECTOR 1
P12 K1KA10A00259 10P CONNECTOR 1
P23 K1KA03A00213 3P CONNECTOR 1
P25 TJS1A8840 8P CONNECTOR 1
P27 K1KA09A00099 9P CONNECTOR 1
PR401 K5Y502B00007 FUSE 1
PR402 K5G162B00008 FUSE 1
PR509,1
0
K5H501Z00005 FUSE 2
Q401 B1DHBD000004 TRANSISTOR 1
Q404 2SB1386RT100 TRANSISTOR 1
Q406 B1DELQ000003 TRANSISTOR 1
Q407 XN4601TX TRANSISTOR 1
Q408 B1CBGD000001 TRANSISTOR 1
Q412,13 B1DEDQ000020 TRANSISTOR 2
Q414,15 B1DAGQ000012 TRANSISTOR 2
Q417 B1CBGD000001 TRANSISTOR 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
Q418 UN5213 TRANSISTOR 1
Q420,21 2SD1819A TRANSISTOR 2
Q422 UN5213 TRANSISTOR 1
Q501,02 2SD1820A TRANSISTOR 2
Q503 UN5211 TRANSISTOR 1
Q504 2SK3065T100 FET 1
Q506 XN0440100L TRANSISTOR 1
Q508 B1GBCFNA0010 TRANSISTOR 1
Q509 XN0440100L TRANSISTOR 1
Q510 2SB1218ARL TRANSISTOR 1
Q511 B1CBGD000001 TRANSISTOR 1
Q512 B1DHBD000004 TRANSISTOR 1
Q513 B1CBGD000001 TRANSISTOR 1
Q514 B1MBACA00006 TRANSISTOR 1
Q515 2SK3065T100 FET 1
Q516 B1DHBD000004 TRANSISTOR 1
Q518 B1MBACA00006 TRANSISTOR 1
Q519 2SK3065T100 FET 1
Q520 B1HFCFA00021 TRANSISTOR 1
Q521 2SD1819A TRANSISTOR 1
Q522 UN5211 TRANSISTOR 1
Q524 2SD1819A TRANSISTOR 1
Q525 XN4601TX TRANSISTOR 1
Q527 B1DEHL000018 TRANSISTOR 1
Q528 2SD1819A TRANSISTOR 1
Q535 2SD1819A TRANSISTOR 1
Q536 B1CFQD000001 TRANSISTOR 1
Q537 B1CHND000004 TRANSISTOR 1
Q538 B1CFQD000001 TRANSISTOR 1
Q540 B1DHBD000004 TRANSISTOR 1
Q541 B1CBGD000001 TRANSISTOR 1
Q542 XN4601TX TRANSISTOR 1
Q544 UN5211 TRANSISTOR 1
Q545 2SK3065T100 FET 1
Q547 2SD1119 TRANSISTOR 1
Q550,51 UNR521L00L TRANSISTOR 2
Q552 UN5213 TRANSISTOR 1
Q553 2SD1819A TRANSISTOR 1
Q554 B1DHBD000004 TRANSISTOR 1
Q555 UN5211 TRANSISTOR 1
R404 ERJ6GEYJ223 M 22KOHM,J,1/10W 1
R408 ERJ6GEYJ104 M 100KOHM,J,1/10W 1
R409 ERJ6ENF1693 M 169KOHM, 1/10W 1
R410 ERF10TJ200 W 20 OHM, 10W 1
R411 D1FZ100E0003 F10OHM 1
R412 ERF10TJ200 W 20 OHM, 10W 1
R413 D1FZ100E0003 F10OHM 1
R414 ERJ8GEYJ153 M 15KOHM, J,1/8W 1
R415 ERJ6GEYJ103 M 10KOHM,J,1/10W 1
R416 ERJ6GEYJ473 M 47KOHM,J,1/10W 1
R417 ERJ6ENF4303 M 430KOHM, 1/10W 1
R418 ERJ6GEYJ473 M 47KOHM,J,1/10W 1
R419 ERJ6GEYJ104 M 100KOHM,J,1/10W 1
R420 ERJ6GEYJ102 M 1KOHM,J,1/10W 1
R421 ERJ6GEYJ333 M 33KOHM,J,1/10W 1
R422 ERJ6GEYJ100 M 10 OHM,J,1/10W 1
R423 ERJ8GEYJ1R0 M 1 OHM, J,1/8W 1
R424 ERJ6GEYJ223 M 22KOHM,J,1/10W 1
R425 ERJ6GEYJ332 M 3.3KOHM,J,1/10W 1
R426 ERJ6GEYJ103 M 10KOHM,J,1/10W 1
R427 ERJ8GEYJ1R0 M 1 OHM, J,1/8W 1
R428 ERJ6GEYJ103 M 10KOHM,J,1/10W 1
R429 ERJ6GEYJ153 M 15KOHM,J,1/10W 1
R430 ERJ6ENF4303 M 430KOHM, 1/10W 1
R431 ERJ6GEYJ103 M 10KOHM,J,1/10W 1
R432 ERJ6GEYJ274 M 270KOHM,J,1/10W 1
R433 ERJ6ENF1202 M 12KOHM, 1/10W 1
R434 ERJ8GEYJ2R2 M 2.2 OHM, J,1/8W 1
R435 ERJ6GEYJ102 M 1KOHM,J,1/10W 1
R436 ERJ8GEYJ153 M 15KOHM, J,1/8W 1
R437 ERJ6GEYJ103 M 10KOHM,J,1/10W 1
R438 ERJ6GEYJ331 M 330 OHM,J,1/10W 1
157
TH-50PHW7BX / TH-50PHW7EX / TH-50PHD7EK / TH-50PHD7ES / TH-50PHD7BK / TH-50PHD7BS / TH-50PHD7UY
To Next Page
